CKSG 低压电容器专用单
三相串联电抗器
Low voltage capacitor special single/three-phase series reactor

CKSG

低压电容器专用单 / 三相串联电抗器

Low voltage capacitor special single/three-phase series reactor

▁ 产品概述 /product overview

电容器在补偿容性无功功率的时候，往往会受到谐波电流，合闸涌流及操作过电压的影响，造成电容损坏和功率因数降低，为此需要在电
容器前端加装串联电抗器，用以抑制和吸收谐波，保护电容器，避免谐波电压电流几冲击电压电流影响，改善电能质量提高系统功率因数，
延长电容器使用寿命。
Capacitor at the time of capacitive reactive power compensation, often by harmonic current, closing the influence of inrush current and
operating over-voltage, which reduces the damage of capacitance and power factor, this need in the front-end reactor with series capacitor,
to suppress and absorb harmonic, protection of capacitor, to avoid a few impulse voltage current harmonic voltage, improve power quality,
improve system power factor to extend the service life of the capacitor.

▁ 型号含义 /model meaning

C - K S G

(干式)自冷
(dry) self-cooling
相数，三相用“S”
Number of phases, three phases, S.
单相用“D”
Single phase with a "D"
电抗器
reactor
串联
In series

▁ 接线方式 /connection mode

K1 K1 67
/
CK CK 68
C
Y形连接 △形连接
Y shape connection △shape connection WWW.JIUKO.COM.CN
