> Power cable

NU-176 NU-177
Copper Conductor PVC Insulated PVC Copper Conductor PVC Insulated PVC
Sheathed Flat Cable Sheathed Flat Cable
(PVC Colour: White, Black, Grey) (PVC Colour: White, Black, Grey)

2
2
NU-176A: 2 x 0.5mm (2 x 1 x 0.79BC) O.D 3.8 x 6.0MM NU-177A: 2 x 0.75mm (2 x 7 x 0.37BC) O.D 4.2 x 6.6MM
2
2
NU-176B: 2 x 0.75mm (2 x 1 x 0.79BC) O.D 4.0 x 6.4MM NU-177B: 2 x 1.0mm (2 x 7 x 0.43BC) O.D 4.3 x 7.0MM
2
2
NU-176C: 2 x 1.0mm (2 x 1 x 1.13BC) O.D 4.1 x 6.5MM NU-177C: 2 x 1.5mm (2 x 7 x 0.52BC) O.D 5.6 x 8.5MM
2
NU-176D: 2 x 1.5mm (2 x 1 x 1.38BC) O.D 4.6 x 7.4MM NU-177D: 2 x 2.5mm (2 x 7 x 0.68BC) O.D 5.6 x 9.3MM
2
2
2
NU-176E: 2 x 2.5mm (2 x 1 x 1.78BC) O.D 5.4 x 8.8MM NU-177E: 2 x 4.0mm (2 x 7 x 0.83BC) O.D 7.1 x 11.2MM
2
NU-176F: 2 x 4.0mm (2 x 1 x 2.25BC) O.D 5.9 x 9.7MM NU-177F: 2 x 6.0mm (2 x 7 x 1.04BC) O.D 7.1 x 11.8MM
2
2
NU-176G: 2 x 6.0mm (2 x 1 x 2.76BC) O.D 6.6 x 10.9MM NU-177G: 2 x 10.0mm (2 x 7 x 1.35BC) O.D 8.5 x 14.5MM
2
NU-178 NU-179
Copper Conductor PVC Insulated PVC Copper Conductor PVC Insulated PVC
Sheathed Multi-core Flat Cable(PVC Colour: Sheathed Flat Cable
White, Black, Grey) (PVC Colour: White, Black, Grey)
2
2
NU-178A: 2 x 0.5mm (2 x 16 x 0.20BC) O.D 4.0 x 6.2MM NU-179A: 3 x 1.0mm (3 x 1 x 1.13BC) O.D 4.1 x 8.8MM
NU-178B: 2 x 0.75mm (2 x 24 x 0.20BC) O.D 4.2 x 6.6MM NU-179B: 3 x 0.75mm (3 x 1 x 1.38BC) O.D 4.6 x 10.1MM
2
2
2
2
NU-178C: 2 x 1.0mm (2 x 32 x 0.20BC) O.D 4.2 x 6.6MM NU-179C: 3 x 1.0mm (3 x 1 x 1.78BC) O.D 5.4 x 12.1MM
2
NU-178D: 2 x 1.5mm (2 x 48 x 0.20BC) O.D 4.7 x 7.5MM NU-179D: 3 x 1.5mm (3 x 1 x 2.25BC) O.D 6.1x 13.8MM
2
NU-178E: 2 x 2.5mm (2 x 77 x 0.20BC) O.D 5.5 x 8.9MM NU-179E: 3 x 2.5mm (3 x 1 x 0.83BC) O.D 6.3 x 14.5MM
2
2
2
2
NU-178F: 2 x 4.0mm (2 x 56 x 0.30BC) O.D 6.0 x 9.8MM NU-179F: 3 x 4.0mm (3 x 1 x 2.76BC) O.D 6.6 x 15.3MM
NU-178G: 2 x 6.0mm (2 x 84 x 0.30BC) O.D 6.7 x 11MM NU-179G: 3 x 6.0mm (3 x 1 x 1.04BC) O.D 6.9 x 16.4MM
2
2
NU-180 NU-181
Power Cable + ECC (PVC Colour: White, Power Cable (PVC Colour: White, Black,
Black, Grey, Yellow) Grey, Yellow)
2
2
NU-180A: 2 x 0.50mm + 1 x 0.25mm O.D 3.2 x 6.3MM NU-181A: 2 x 1.0mm (2 x 1 x 1.13BC) O.D 4.2 x 7.7MM
2
2
2
NU-180B: 2 x 0.75mm + 1 x 0.35mm O.D 4.0 x 6.6MM NU-181B: 2 x 1.5mm (2 x 1 x 1.38BC) O.D 4.7 x 8.8MM
2
2
2
NU-180C: 2 x 1.0mm + 1 x 0.50mm O.D 4.2 x 6.8MM
2
NU-181C: 2 x 2.5mm (2 x 1 x 1.78BC) O.D 5.6 x 11.2MM
2
2
NU-180D: 2 x 1.5mm + 1 x 0.75mm O.D 4.7 x 8.0MM 2
2
2
NU-180E: 2 x 2.5mm + 1 x 1.25mm O.D 5.6 x 9.5MM NU-181D: 2 x 4.0mm (2 x 1 x 2.25BC) O.D 6.0 x 12.0MM
2
NU-180F: 2 x 4.0mm + 1 x 2.0mm 2 O.D 6.0 x 11.0MM NU-181E: 2 x 6.0mm (2 x 1 x 2.76BC) O.D 6.5 x 13.0MM
2
NU-182 NU-183
H07V-R Double Core Flat Cables Solid Conductor Insulated Single Core Alu-
minium Wire(PVC Colour:RED, Black, Grey,
Yellow/Green, Brown, Blue, Yellow)
Size 30/29 NU-183A: 1 x 0.75mm (1 x 0.97AL) O.D 2.0MM
2
2
2
NU-182A: 2 x 0.21mm (2 x 3 x 0.30BC) O.D 4.0 x 6.1MM NU-183B: 1 x 1.0mm (1 x 1.13AL) O.D 2.3MM
NU-183C: 1 x 1.5mm (1 x 1.38AL) O.D 2.8MM
2
2
Size 70/29 NU-183D: 1 x 2.5mm (1 x 1.78AL) O.D 3.4MM
2
2
NU-182B: 2 x 0.50mm (2 x 7 x 0.30BC) O.D 5.3 x 8.8MM NU-183E: 1 x4.0mm 1 x 2.25AL) O.D 3.9MM
NU-183F: 1 x 6.0mm (1 x 2.76AL) O.D 4.0MM
2
