P. 185
Wenzhou Xika
Electrical Co.,Ltd.
> Power cable
NU-184 NU-187
Solod Conductor Insulated Single Core Alu- Auto Power Cable(Transparent)
minium Wire(PVC Colour: Red, Black,Grey,
Yellow/Green, Brown, Blue,Yellow)
NU-187A: 20GA 0.519mm 2 O.D 2.2MM
NU-187B: 18GA 0.81mm 2 O.D2.5MM
NU-187C: 16GA 1.31mm 2 O.D3.2MM
NU-184A: 1 x 1.0mm (7 x 0.43AL) O.D 2.5MM NU-187D: 14GA 2.08mm 2 O.D3.6MM
2
NU-187E: 12GA 3.31mm 2 O.D4.5MM
2
NU-184B: 1 x 1.5mm (7 x 0.52AL) O.D 3.0MM
NU-187F: 10GA 5.22mm 2 O.D5.5MM
2
NU-184C: 1 x 2.5mm (7x 0.68AL) O.D 3.6MM
NU-187G: 8GA 8.31mm 2 O.D6.6MM
2
NU-184D: 1 X 4.0mm (7x 0.83AL) O.D 4.1MM
NU-187H: 6GA 13.29mm 2 O.D8.0MM
NU-184E: 1 x 6.0mm (7 x 1.04AL) O.D 4.7MM NU-187I: 4GA 21.15mm 2 O.D10.0MM
2
2
NU-184F: 1 x 10.0mm (7 x 1.35AL) O.D 6.1MM NU-187J: 2GA 33.62mm 2 O.D12.5MM
2
NU-184G: 1 x 16.0mm (7 x 1.70AL) O.D7.1MM NU-187K: 0GA 53.16mm 2 O.D 15.8MM
> Electrical Wire
NU-188
Electrical Wire(Parallel)
PVC Colour: White, Balck, Red/White, Grey,
Brown
NU-188A: 2 x 0.25mm 2 O.D 2.0 x 4.0MM
NU-188B: 2 x 0.50mm 2 O.D2.2 x 4.4MM
NU-188C: 2 x 0.75mm 2 O.D2.5 x 5.0MM
NU-188D: 2 x 1.00mm 2 O.D3.0 x 6.0MM
NU-188E: 2 x 1.50mm 2 O.D3.5 x 7.0MM
NU-188F: 2 x 2.0mm 2 O.D3.8 x 7.5MM
NU-188G: 2 x 2.5mm 2 O.D4.0 x 8.0MM
NU-188H: 2 x 4.0mm 2 O.D5.0 x 10.0MM
NU-188I: 2 x5.0mm 2 O.D5.5 x 11.0MM
NU-188J: 2 x 6.0mm 2 O.D6.0 x12.0MM
NU-189 NU-190
White Electrical Wire£ (Parallel) Standard Guage White Electrical Wire
(Parallel)
NU-189A: 26AWG 2 x 7/0.12 O.D 2.0 x 4.0MM NU-190A: 26AWG 2 x 12/0.12 O.D 1.7 x 3.4MM
NU-189B: 24AWG 2 x 12/0.12 O.D2.2 x 4.4MM NU-190B: 24AWG 2 x 14/0.14 O.D1.8 x 3.6MM
NU-189C: 22AWG 2 x 15/0.12 O.D2.5 x 5.0MM NU-190C: 22AWG 2 x 12/0.18 O.D1.9 x 3.8MM
NU-189D: 20AWG 2 x 20/0.12 O.D3.0 x 6.0MM NU-190D: 20AWG 2 x 10/0.25 O.D2.2 x 4.4MM
NU-189E: 18AWG 2 x 30/0.12 O.D3.5 x 7.0MM NU-190E: 18AWG 2 x 16/0.25 O.D2.5 x 5.0MM
NU-189F: 14AWG 2 x 50/0.12 O.D3.8 x 7.5MM NU-190F: 14AWG 2 x 30/0.18 O.D2.5 x 5.0MM
www.seicae.com
NU-189G: 14AWG 2 x 70/0.12 O.D4.0 x 8.0MM NU-190G: 14AWG 2 x 24/0.25 O.D3.0 x 6.0MM
NU-189H: 12AWG 2 x 100/0.12 O.D5.0 x 10.0MM NU-190H: 12AWG 2 x 40/0.25 O.D3.4 x 6.8MM
NU-189I: 10AWG 2 x 120/0.12 O.D5.5 x 11.0MM NU-190I: 10AWG 2 x 62/0.25 O.D3.9 x 7.8MM
NU-189J: 8AWG 2 x 160/0.12 O.D6.0 x12.0MM NU-190J: 8AWG 2 x 413/0.12 O.D5.5 x10.0MM
>F 173
