EntelliGuard* L

Spare Parts for Power Circuit Breakers

Breaker arc chutes
Envelope 1 Envelope 2
Cat. No. Ref. No. Cat. No. Ref. No.
Arc chute for 1 pole L25NCHT 444407 L40DCHT 444411

Breaker fixed arcing contacts
Set for 1pole all tiers (1) L25NARC 444404 L40DARC 444410

Order codes Breaker: Door flanges Door flange fixed (1) (1) LDPRF 444200 LDPRF 444200

GDPRW
Door flange drawout
408026
GDPRW
408026
IP54 cover
Front facia cover IP54 GGDEFD 408038 GGDEFD 408038
Intro

A Cassette racking handle
Racking handle (1) LRHN 444412 LRHN 444412

B

Breaker front fascia part (1)
Front fascia 3 or 4 pole (2) LFAL1 444413 LFAL2 444414
C

D
Cassette cluster contacts
Sets per pole (1)
Current rating 400-1250A L13NCLS 444405
E Current rating 1600A L16NCLS 444406
L25NCLS
Current rating 2000-2500A
444408
Current rating 2000-4000A L40DCLS 444409
Set of universal cluster pliers GUNI 408047 GUNI 408047
X

Disconnect terminals
For fixed or draw-out breaker LSDT 444415 LSDT 444415
(B & C block 32 pole) (1)

Lifting Beam & Lifting Truck
Lifting beam for use with
standard lifting equipment GLB1 408045 GLB1 408045

Lifting truck GE-1000 - GE-1000 -

(1) These Parts are supplied as standard along with breakers. (Can also be ordered as Spare).
(2) The original breaker serial number must be indicated on ordering

A.14
