EntelliGuard* L

Isolators or Non Automatic breakers executed in a fixed
mounting pattern

- With horizontal rear connection. (For other options, please refer to page A.7)
- With auxiliary contact block equipped with 3 NO and 3 NC contacts

3 pole 4 pole left 4 pole right
Rating (A) Cat. No. Ref. No. Cat. No. Ref. No. Cat. No. Ref. No.
400 LJ04R4 444161 LJ04R6 444173 LJ04R5 444390
R type 630 LJ07R4 444162 LJ07R6 444174 LJ07R5 444391
Icw=42kA 800 LJ08R4 444163 LJ08R6 444175 LJ08R5 444392 Non standard connection options
1000 LJ10R4 444164 LJ10R6 444176 LJ10R5 444393
1250 LJ13R4 444165 LJ13R6 444177 LJ13R5 444394
1600 LJ16R4 444166 LJ16R6 444178 LJ16R5 444395
2000 LJ20R4 444167 LJ20R6 444179 LJ20R5 444396
2500 LJ25R4 444168 LJ25R6 444180 LJ25R5 444397
2000 LJ20C4 444169 LJ20C6 444181 LJ20C5 444398
C type 2500 LJ25C4 444170 LJ25C6 444182 LJ25C5 444399
Icw=50kA 3200 LJ32C4 444171 LJ32C6 444183 LJ32C5 444400
4000 LJ40C4 444172 LJ40C6 444184 LJ40C5 444401

Intro

Isolators or Non Automatic breakers: Drawout
Breakers; Moving portion only A

- With auxiliary contact block equipped with 3 NO and 3 NC contacts
- A cassette is needed, please refer to page A.7 for options
B

3 pole 4 pole left 4 pole right
Rating (A) Cat. No. Ref. No. Cat. No. Ref. No. Cat. No. Ref. No. C
400 LJ04R1 444135 LJ04R3 444147 LJ04R2 444378
R type 630 LJ07R1 444136 LJ07R3 444148 LJ07R2 444379
Icw=42kA 800 LJ08R1 444137 LJ08R3 444149 LJ08R2 444380
1000 LJ10R1 444138 LJ10R3 444150 LJ10R2 444381 D
1250 LJ13R1 444139 LJ13R3 444151 LJ13R2 444382
1600 LJ16R1 444140 LJ16R3 444152 LJ16R2 444383
2000 LJ20R1 444141 LJ20R3 444153 LJ20R2 444384
2500 LJ25R1 444142 LJ25R3 444154 LJ25R2 444385
E
2000 LJ20C1 444143 LJ20C3 444155 LJ20C2 444386
C type 2500 LJ25C1 444144 LJ25C3 444156 LJ25C2 444387
Icw=50kA 3200 LJ32C1 444145 LJ32C3 444157 LJ32C2 444388
4000 LJ40C1 444146 LJ40C3 444158 LJ40C2 444389 X
Trip Unit Configurable at 0.50 or 100% of phase rating
