铝合金桥架-型材桥架 铝合金桥架-型材桥架
Al-alloy Type Al-alloy Type

LQJ-T型梯级式桥架 LQJ-ST(R)型水平三通
LQJ-T Ladder Frame LQJ-ST(R) Horizontal T-joint

型 号 宽 度 高 度 备注
Model W H Remark
型 号 宽 度 高 度
Model W H LQJ-ST(R)-6-10 100
LQJ-T-6-10 100 LQJ-ST(R)-6-20 200 60
LQJ-T-6-20 200 60 LQJ-ST(R)-6-30 300
LQJ-T-6-30 300 LQJ-ST(R)-6-40 400
LQJ-T-6-40 400 LQJ-ST(R)-10-20 200
LQJ-T-10-20 200 LQJ-ST(R)-10-30 300
LQJ-T-10-30 300 LQJ-ST(R)-10-40 400
LQJ-T-10-40 400 LQJ-ST(R)-10-50 500 100
LQJ-T-10-50 500 100 LQJ-ST(R)-10-60 600
LQJ-T-10-60 600 LQJ-ST(R)-10-80 800 R=300
LQJ-T-10-80 800 LQJ-ST(R)-10-100 1000
LQJ-T-10-100 1000 LQJ-ST(R)-15-40 400
LQJ-T-15-40 400 LQJ-ST(R)-15-50 600 150
LQJ-T-15-50 600 LQJ-ST(R)-15-60 800
150
LQJ-T-15-60 800 LQJ-ST(R)-15-80 1000
LQJ-T-15-80 1000 LQJ-ST(R)-20-40 400
LQJ-T-20-40 400 LQJ-ST(R)-20-60 600 200
LQJ-T-20-60 600 200 LQJ-ST(R)-20-80 800
LQJ-T-20-80 800 LQJ-ST(R)-20-100 1000
LQJ-T-20-100 1000 注：如需圆弧型弯头，订货时请注明并告知弯曲半径
轻型Light duty 重型heavy duty Note:If arc elbow is needed,bend radius shall be informed when ordering.

LQJ-ST4(R)型水平四通
H
LQJ-RT(R)型水平弯通 LQJ-ST4(R) Horizontal cross joint
LQJ-RT(R) Horizontal Elbow
B
L
型 号 宽 度 高 度 备注 型 号 宽 度 高 度 备注
Model W H Remark Model W H Remark
LQJ-RT(R)-6-10 100 LQJ-ST4(R)-6-10 100
LQJ-RT(R)-6-20 200 LQJ-ST4(R)-6-20 200
LQJ-RT(R)-6-30 300 60 LQJ-ST4(R)-6-30 300 60
H
LQJ-RT(R)-6-40 400 LQJ-ST4(R)-6-40 400
LQJ-RT(R)-10-20 200 LQJ-ST4(R)-10-20 200
LQJ-RT(R)-10-30 300 LQJ-ST4(R)-10-30 300
B
L
LQJ-RT(R)-10-40 400 LQJ-ST4(R)-10-40 400
LQJ-RT(R)-10-50 500 100 LQJ-ST4(R)-10-50 500 100
LQJ-RT(R)-10-60 600 LQJ-ST4(R)-10-60 600
LQJ-RT(R)-10-80 800 R=300 LQJ-ST4(R)-10-80 800 R=300
LQJ-RT(R)-10-100 1000 LQJ-ST4(R)-10-100 1000
LQJ-RT(R)-15-40 400 LQJ-ST4(R)-15-40 400
H
LQJ-RT(R)-15-50 600 LQJ-ST4(R)-15-50 600 150
LQJ-RT(R)-15-60 800 150 LQJ-ST4(R)-15-60 800
B 铝 合金
LQJ-RT(R)-15-80 1000 LQJ-ST4(R)-15-80 1000
L
LQJ-RT(R)-20-40 400 LQJ-ST4(R)-20-40 400
LQJ-RT(R)-20-60 600 200 LQJ-ST4(R)-20-60 600 200
LQJ-RT(R)-20-80 800 LQJ-ST4(R)-20-80 800
LQJ-RT(R)-20-100 1000 LQJ-ST4(R)-20-100 1000
注：如需圆弧型弯头，订货时请注明并告知弯曲半径 注：如需圆弧型弯头，订货时请注明并告知弯曲半径
Note:If arc elbow is needed,bend radius shall be informed when ordering. Note:If arc elbow is needed,bend radius shall be informed when ordering.
H
B
L
35 CABLE SUPPORT SERIES CABLE SUPPORT SERIES 36
