铝合金桥架       铝合金桥架-线槽系列
 Al-alloy Type  Al-alloy Type




 型式和技术参数
 1.LQJ 系列铝合金桥架可分为梯级式、槽式、托盘式,分别用T、C、P表示。  LQJ铝合金线槽系列
 2.梯级式桥架具有良好的通风性能,不防尘,不防干扰。槽式桥架具有防尘、防干扰性能。
 3.桥架长度≤6m,当长度>6m  时可接受特殊订货。          LQJ Al-alloy Cable Tray Model
 4.梯级式、槽式载荷性能参照下图:
 TYPES AND TECHNICAL PARAMETRES

 1.LQJ series of aluminum alloy  cable tray can be divided into ladder-shaped and trough shaped ones, separately
 represented by T, C and P.
 2.Ladder-shapped cable tray is provided with perfect air permeability, but not with performance of dust proof and
 interference proof. Channel-type cable tray is provided with performance of dust proof and interference proof





 Channel cable tray
                                           H
 h=100
 Ladder cable tray                          B
 h=100
 均布载荷 kg/m  Distribution Load  Channel cable tray




 Ladder cable tray



                                              H
 挠度mm  支撑距离2米
 Flexibility  Supporting distance 2m          B

 Channel cable tray
 h=100


 Ladder cable tray
 h=100                                型     号
                                       Model                  H                   W
                                    LQJ-WC-2.5-5
                                                                                  50
 均布载荷 kg/m  Distribution Load  Channel cable tray  LQJ-WC-2.5-10  25              100
                                                                                  150
                                    LQJ-WC-2.5-15
                                    LQJ-WC-2.5-20
                                                                                  200
                                                                                  50
                                     LQJ-WC5-5
                                                                                  150
                                     LQJ-WC5-15
 Ladder cable tray                   LQJ-WC5-10               50                  100
                                     LQJ-WC5-20                                   200                             铝 合金
                                     LQJ-WC10-5                                   100
                                     LQJ-WC10-10                                  150
                                                             100
                                     LQJ-WC10-15                                  200
                                     LQJ-WC10-20                                  250
 挠度mm  支撑距离2米
 Flexibility  Supporting distance 2m
