KC-BXD-500
防爆配电箱
Explosion-proof distribution box

选型表/Selection table

主回路 主回路 主回路进线 主回路进线口 支路出线口
总开关数(台) 口螺纹 电缆外径(mm) 支路额定电
型号 支路数 Main circuit 额定电流(A) Main Main circuit 流(A) 支路出线口螺纹 电缆外径(mm)
Number of Main circuit Branch outlet Branch outlet
Model branches Total number circuit inlet Branch rated thread
Cable outer
of switches Rated current inlet Cable outer current (A) diameter (mm)
(A)
(stage) thread diameter (mm)
BXM(D)-4 4

BXM(D)-6 6

BXM(D)-8 8 / / / /

BXM(D)-10 10
G3/4"
1~16 ф8~ф14
BXM(D)-12 12 G1"
20~25 ф12~ф17
G2"
32~50 ф15~ф23
BXM(D)-4K 4 ≤32 G1 1/4" ф15~ф23 G1 1/4"
63 ф18~ф23
G1 1/2"
BXM(D)-6K 6 40~63 G1 1/2" ф18~ф33

BXM(D)-8K 8 1 80~160 G2 ф26~ф34

BXM(D)-10K 10 180~225 G2 1/2" ф30~ф43

BXM(D)-12K 12 250 G3 ф35~ф51

订货须知/Ordering instructions

● 订货时应注明配电箱的支路数、各支路相应的电流以及断路器的极数，若需带漏电保护功能请注明；
● 如需带总开关则请注明总开关的电流及极数，并注明进出线方向，进出线规格及对应的数量；
● BXM(D)系类防爆照明（动力）配电箱，可根据用户要求进行特殊设计，用户需提供电气系统图。
● When ordering, please indicate the number of branches of the distribution box, the corresponding current of each branch and the number of poles of
the circuit breaker. If you need to bring the leakage protection function, please indicate;
● If you want to bring the main switch, please indicate the current and the number of poles of the main switch, and indicate the direction of the incoming
and outgoing lines, the specifications of the incoming and outgoing lines and the corresponding quantity;
● BXM (D) series explosion-proof lighting (power) distribution box, can be specially designed according to user requirements, users need to provide
electrical system diagram.
