KC-BXD-500
防爆配电箱
Explosion-proof distribution box

型号及含义/Type and meaning

KC - BXD - 500

额定电流 / Rated current
防爆配电箱 / Explosion-proof distribution box
企业代号 / Enterprise code

产品特点/Features

● 壳体采用铝合金铸造或钢板焊接成型，表面粉末静电喷塑;
● 内装高分段小型断路器或塑壳断路器，有DZ47、 iC65、 DZ158、NM1、CM1等;
● 产品采用复合型、开关箱采用隔爆型结构、母线箱及出线箱采用增安型结构，腔体均设有密封圈，具有良好的防水、防尘功能;
● 具有过载、短路等功能，可根据用户要求增加漏电保护功能;
● 电缆或钢管布线;
● 可根据用户要求特质。
● The shell is made of aluminum alloy casting or steel plate welding, and the surface powder is electrostatically sprayed;
● Built-in high-segment miniature circuit breaker or molded case circuit breaker, including DZ47, iC65, DZ158, NM1, CM1, etc.;
● The product adopts composite type, the switch box adopts explosion-proof structure, the bus box and the outlet box adopt the increased safety structure,
and the cavity is provided with sealing ring, which has good waterproof and dustproof functions;
● With overload, short circuit and other functions, the leakage protection function can be increased according to user requirements;
● Cable or steel pipe wiring;
● According to user requirements.

技术参数/Technical parameter

● 执行标准: GB3836. 1-2010、GB3836.2-2010、GB3836.3-2010、GB12476.1-2013、GB12476.5-2013;
● 防爆标志: Exde II BT4 Gb、Exde II CT4 Gb、Ex tD A21 IP65 T80℃;
● 额定电压: 220V/AC380V;
● 主回路额定电流: 63A~250A
● 支路额定电流: 1A、2A、4A、6A、10A、16A、 20A、25A、32A、40A、 50A、 63A;
● 防护等级: IP54、 IP65;
● 防腐等级: WF1*WF2。
● Implementation standards: GB3836. 1-2010, GB3836.2-2010, GB3836.3-2010, GB12476.1-2013, GB12476.5-2013;
● Explosion-proof signs: Exde II BT4 Gb, Exde II CT4 Gb, Ex tD A21 IP65 T80°C;
● Rated voltage: 220V/AC380V;
● Main circuit rated current: 63A~250A
● Branch rated current: 1A, 2A, 4A, 6A, 10A, 16A, 20A, 25A, 32A, 40A, 50A, 63A;
● Protection level: IP54, IP65;
● Anti-corrosion level: WF1*WF2.
