配电箱
Distribution box
PZ30
司 智 电 重 庆 科 限 公 技 有
概述 / Overview
PZ30-A 终端组合配电箱系列主要结构部件有透明罩、上盖、箱体、安装轨、轨道高低调节螺杆、导电排、护线罩和电器开关元件等。内装电器
开关元件全部采用宽度 9mm 模数的电器，安装于顶帽形轨道上，可根据需要任意组合，安装轨道高低可调节，特别对暗装式更为方便。拆装迅速
方便、开关元件手柄外露，带电及其它部分遮盖于上盖内部，打开门可方便地操作，使用安全可靠，箱体上下、左右及背后均设置进出线孔，便于
接线。
PZ30-B( 原型号 PZ30X) 模数化终端组合配电箱系列是一种安装模数为 9mm 终端电器的装置，它适用于交流 50Hz，额定电压 220V 与 380V
的住宅、车站、商业网和工矿企业的配电中作为对用电设备进行控制，对过载、短路、过电压和漏电起保护作用的一种成套装置。
PZ30-B 模数化终端组合配电箱系列分明装 / 暗装两种类型。
The main structural components of the PZ30-A terminal combination distribution box series include transparent cover, upper cover,
box body, mounting rail, track height adjusting screw, conductive row, wire shield and electrical switch components. The built-in
electrical switch components are all equipped with electric appliances with a width of 9mm and are mounted on the top hat-shaped
track. They can be combined according to the needs. The height of the installation rail can be adjusted, especially for the concealed
type. The disassembly and assembly is quick and convenient, the handle of the switch component is exposed, and the electrified and
other parts are covered inside the upper cover. The door can be easily operated, and the use is safe and reliable. The inlet and outlet
holes are arranged on the upper, lower, left and right sides of the cabinet to facilitate wiring.
...................................................................................................
