YINGMING POWER

GCK

LOW-VOLTAGE WITHDRAWABLE
SWITCHGEAR

Overview
GCK low-voltage withdrawable switchgear consists of two parts: power distribution center (PC) cabinet and motor control center (MCC). It is suitable
for power users such as power plants, substations, industrial and mining enterprises, etc. as AC 50Hz, maximum working voltage to 660V, maximum
working. The current is distributed to the 3150A power distribution system for power distribution and distribution control of power distribution
equipment such as power distribution, motor control and lighting.

Model and meaning
G C K □

Main circuit scheme number
Use code
Withdraw
Enclosed switchgear

Use environment
● The altitude does not exceed 2000m;
● The ambient air temperature is not higher than + 40 ℃ , and the average temperature within 24h is not higher than +35 ℃ , and the ambient air
temperature is not lower than -50℃ ;
● Atmospheric conditions: The air is clean, the relative humidity does not exceed 50% at a temperature of +40℃ , and the higher relative humidity is
allowed at a lower temperature, such as: 90% at +20℃ ;
● There is no fire, explosion hazard, serious pollution, chemical corrosion and severe vibration;
● It is inclined to 5° from the vertical plane;
● This product is suitable for the following temperature transportation and storage: -25℃ ~ +55℃ , in a short time (not more than 24h) does not exceed
+70 ℃ .
Note: If the above conditions of use cannot be met, the user shall submit it to the manufacturer at the time of ordering and negotiate settlement.
