3.2. EXTENSIVE SPECIFICATIONS
Cubicles consist of 2 mm galvanized steel plates. By opt- located high enough to install the terminals in the cubicle.
ing for this particular plate size, the cubicles are able to
withstand internal arcs effortlessly, both Manual operation of the cubicles re-
in the cable compartment as well as in the quires minimal switch force. The clean and
busbar compartment. neat synoptic diagram provides a clear and
BUILT safe overview of the different positions of
A lot of detail went into the functional the various parts of the cubicle.
design to ensure that, in the event of an TO LAST!
internal malfunction, no bursts of flames The accessories (such as floor panels and
can move between plating surfaces, the busbars) are stored in boxes and ensure
door or between cubicles. easy assembling of the cubicles.
Possible internal arcs are also guaranteed The cubicles and their corresponding
to be restricted to the compartment where parts can be equipped with a wide range
they originated. The roof of the cubicle can be easily dis- of optional features on request, in order to offer expert
mantled to provide smooth access to the busbar during solutions to your needs.
installation and/or maintenance activities.
The copper busbar is manufactured to resist the current,
which results in minimum heating at the contact points.
SGC - SwitchGear Company’s countless years of
experience resulted in a cable compartment as
comfortable and as functional as possible.
The operator has maximum access to the connection
points. This is crucial when (dis)assembling cables and
fuses, and during maintenance work. Moreover, it will
save time and lead to less industrial accidents.
The high voltage cables can be supported by cable sup-
ports and the connection point in every type of cubicle is
“The cubicles can
be equipped with a
wide range of
OTHER OPTIONS & DIMENSIONS?
optional features...” Please consult us for options and dimensions
other than those mentioned in this catalogue.
