Anchor Clamp, Suspension Clamp & Bracket

NLL Series Metal Wedge Clamp

NLL series bolt type aluminum alloy strain clamp is applicable to 35kV and below aerial circuits. To fix aluminum stranded conductor
or steel core aluminum straned conductor. For matching insulating aluminum cover when using aerial insulating aluminum
conductor, for insulating safety action.

Type Cable Diameter(mm) Breaking Load(kN) U Bolt Otv
NLL-1 5.0-15.5 60 2
NLL-2 8.5-19.6 60 2
NLL-2A 8.0-15 60 2
NLL-2B 8.0-15 60 2
NLL-3 11.4-22.6 80 2
NLL-3A 11.4-22.6 80 3

NLL-4 13-26.4 80 3
NLL-4A 13-26.4 81 3
NLL-1 G 5-16 / 2
NLL-2G 5-21 / 2

Bracket

CA25 CA1500 CA1600

CA16 ES1500L PS1000L
