FZBWL-12 模块化智能预制舱式变电站
www.shfateng.com
智能路灯照明箱变 专注细节 品质取胜
Intelligent street lighting box change Focus on the details of quality to win

概述 Overview

FZBWL-12 型智能路灯照明箱变是专为路灯提供供用电设计的箱式变电站。主要采用欧式箱变结构，其区别于普通欧式箱变的地方主要在于低压部分采用路
灯自动控制器和路灯控制接触器，可靠保证路灯系统的准确供电。智能路灯照明箱变是一种高压开关设备、配电变压器和低压配电装置，按一定接线方案排
成一体的工厂预制户内、户外紧凑式配电设备，即将高压受电、变压器降压、低压配电等功能有机地组合在一起，安装在一个防潮、防锈、防尘、防鼠、防火、
防盗、隔热、全封闭、可移动的钢结构箱体内，机电一体化，全封闭运行，特别适用于城网建设与改造，是继土建变电站之后崛起的一种崭新的节能型变电站。 最新小型柜
FZBWL-12 intelligent street light box is designed for street lamps designed for power supply box-type substation. Mainly used in the European box variable
structure, which is different from the ordinary European box changes mainly in the low-voltage part of the automatic control of street lamps and street lights control
contactor, reliable to ensure accurate power supply street system. Intelligent street lighting box change is a high-voltage switchgear, distribution transformers and
low-voltage power distribution devices, according to a certain wiring program into one of the factory prefabricated indoor and outdoor compact power distribution
equipment, will be high-voltage power, Low-voltage power distribution and other functions organically combined together, installed in a moisture, rust, dust,
rodent, fire, security, heat insulation, fully enclosed, movable steel box, mechanical and electrical integration, , Especially for urban network construction and
transformation, is following the rise of civil substation after the rise of a new energy-saving substation.
品牌授权柜 GE

适用范围 Applicable scope
■ 城市电网电缆入地改造； ■ urban power grid cable into the transformation；
■ 街道路灯改造； ■ street lights transformation； 箱式变电站
■ 城市环网系统； ■ city ring network system；
■ 大用户电源分配； ■ Large user power distribution；
■ 生活小区； ■ living area；
■ 铁路车站供电。 ■ Railway station power supply。
高压开关柜

使用条件 Service condition
■ 环境温度：最高温度 +40℃，最低温度 -25℃；
低压开关柜
■ 环境湿度：日相对湿度平均值不超过 95%，月相对湿度平均值不超过 90%；
■ 海拔高度：不超过 1000 米；
■ 风速：户外风压不超过 700Pa(34m/s)；
2
2
■ 防震：水平加速度不大于 3m/s ，水平加速度 1.5 m/s ；
■ 安装地点倾斜度：不大于 3 度； 电缆分支箱、元件及配电系统
■ 安装环境：周围空气不受腐蚀性，可燃性气体等明显污染，安装地点无剧烈震动；
■ 超过上述条件规定时，可与本公司协商决定。
■ Ambient temperature: maximum temperature +40℃ , the lowest temperature -25℃ ;
■ Ambient humidity: Daily average relative humidity of not more than 95%, the average monthly relative humidity of not more than 90%;
■ Altitude: no more than 1000 meters;
■ wind speed: outdoor wind pressure does not exceed 700Pa (34m/s);
2
2
■ shock: the level of acceleration is not greater than 3m/s , the level of acceleration 1.5 m/s ;
■ Installation site inclination: no more than 3 degrees;
■ installation environment: the surrounding air from corrosive, flammable gas and other obvious pollution, the installation site without severe vibration;
■ When the above conditions are met, it may be decided in consultation with the Company.
