KCSRM16-12
气体绝缘金属封闭开关设备
Gas insulated metal enclosed switchgear

外形尺寸及安装基础图/Dimensions and installation base

DBCJOFU DBCJOFU

'SPOU PG UIF DBCJOFU
'SPOU PG UIF DBCJOFU
12kV M柜地基尺寸图/12kV M cabinet foundation size chart

说明：以上数据仅供参考，我公司保留修改数据的权利。
Note: The above data is for reference only, our company reserves the right to modify the data.

订货须知/Ordering instructions

● 确定产品型号、名称代号、主要技术参数；
● 确定产品数量、交货周期；
● 其他特殊的运行要求；
● 备品备件名称及数量；
● Determine the product model, name code, and main technical parameters;
● Determine the quantity of products and delivery period;
● Other special operational requirements;
● Name and quantity of spare parts;

产品存储及维护/Product storage and maintenance
● 包装好的产品在运输和装卸过程中，禁止倒置、强烈震动和碰撞；
● 产品储存于干燥、通风、防潮的室内或仓库中，长期存放需在传动部位进行润滑防护处理，并定期检查环境状况，产品储存年限为15年；
● 运行中的产品每隔3-5年进行—次小检，主要检查机构部分运动件的磨损情况和紧固件的状况，清除绝缘件表面灰尘，在活动部分添加润滑剂。
● Inverted, strong vibration and collision are prohibited during the transportation and loading and unloading of the packaged products;
● The product is stored in a dry, ventilated, moisture-proof room or warehouse. For long-term storage, it is necessary to carry out lubrication protection
treatment at the transmission part, and regularly check the environmental conditions. The product storage period is 15 years;
● The products in operation are carried out every 3-5 years - a small inspection, mainly to check the wear of some moving parts of the mechanism and
the condition of the fasteners, to remove the dust on the surface of the insulation, and to add lubricant to the movable part.
