YM
TEMPERATURE AND
HUMIDITY CONTROLLER SERIES YINGMING POWER
YM-SK-SX(TH) single intelligent digital humidity controller
The main function
It has one-way humidity control and one-way output, which can monitor
the humidity of the measured environment in real time, so that the
environmental humidity index meets the requirements and can effectively
:. 4, 49 CBTF XJSJOH EJBHSBN
prevent the generation of the condenser. The set value or measured
$POUSPM JOEJDBUJPO
value of the humidity is displayed numerically; the user sets the humidity
"$ 7
)VNJEJUZ 4FOTPS )VNJEJUZ DPOUSPM VOJU control bit by the button.
)VNJEJUZ
MPBE

Technical characteristics
:. 4, 49 QBOFM XJSJOH EJBHSBN
◆ Power supply voltage: AC220V 50Hz;
)VNJEJUZ 4FOTPS
◆ Measurement control range: -50~99℃ Accuracy ±1℃ ;

$POUSPM JOEJDBUJPO )VNJEJUZ DPOUSPM VOJU
◆ Parameter setting: upper limit: -49~99℃ ; lower limit: -50~98℃

Note: This figure is for reference ◆ Sensor error correction: -50~99℃ ;
only. Please refer to the actual "7 7 )VNJEJUZ MPBE
product for the specific wiring! ◆ Display mode: three LED digital tube display. 1 decimal place;
◆ Response speed: typical value ≤ 5S;
◆ Load output capacity: AC220V/7A (resistive load) one active output;
◆ Volume: 48×48×78mm.
YM-ZWS-42-2W dual intelligent digital temperature controller
The main function
YM-ZWS-42-2W intelligent temperature controller with two-way temperature digital
display control. Real-time and precise monitoring of the temperature of the measured
environment. Make the ambient temperature indicator meet the job requirements. The
set value or measured value of the temperature is displayed numerically; the user sets
5FNQFSBUVSF QPXFS TVQQMZ
4FOTPS the temperature control value by the button. And can automatically alarm the short

circuit fault of the heating (cooling) device. The product integrates the heating and

heating type and the fan cooling type.

5FNQFSBUVSF 5FNQFSBUVSF Technical characteristics
4FOTPS MPBE
5FNQFSBUVSF
MPBE ◆ Power supply voltage: AC220V 50Hz;

◆ Measurement control range: -50~99℃ Accuracy ±1℃ ;
"MBSN 0VUQVU
◆ Parameter setting: upper limit: -49~99℃ Lower limit: -50~98℃ ;
◆ Sensor error correction: -50~99℃ ;
◆ Display mode: three LED digital tubes on the top and bottom display, 1 decimal place;
◆ Response speed: typical value ≤ 5S;
◆ Load relay output capacity: AC220V/5A (resistive load) two active outputs;
◆ Alarm relay output capacity: AC220V/5A (resistive load) one passive output;
◆ Volume: 72×72×95mm.
YM-ZWS-42-2S(TH) dual intelligent digital display humidity controller
The main function
YM- ZWS-42-2S (TH) intelligent humidity controller has two digital humidity control,
which can monitor the humidity of the tested environment in real time, so that the
environmental humidity index meets the requirements and can effectively prevent
QPXFS TVQQMZ
)VNJEJUZ condensation. . The set value or measured value of the humidity is displayed numerically.
TFOTPS

The user can set the humidity control value by the button and can automatically alarm
the short circuit fault of the heating device.
The product combines heating and heating and fan dehumidification.
)VNJEJUZ
TFOTPS
)VNJEJUZ )VNJEJUZ
MPBE MPBE Technical characteristics

◆ Power supply voltage: AC220V 50Hz;

"MBSN 0VUQVU ◆ Measurement control range: 0-100% RH accuracy ± 3% RH;
◆ Parameter setting: upper limit: 2-99% RH lower limit: 1-98% RH;

◆ Display mode: three LED digital tubes on the top and bottom display, 1 decimal place;
◆ Response speed: typical value ≤ 5S;
◆ Load relay output capacity: AC220V/5A (resistive load) two active outputs;
◆ Alarm relay output capacity: AC220V) 5A (resistive load) one passive output;
◆ Volume: 72×72×135mm.
68
