CCX(KBC-1)照明母线槽 HX安全供电滑触母线

CCX(KBC-1)照明母线槽 HX安全供电滑触母线
HX Safety power supply trolley bus
CCX(KBC-1) Lighting Busbar Trunking 系统说明System Introduction
HX安全供电滑触母线装置可用于电动胡芦、电动门式和桥式起重机、推机等全储设施，移动式电动工
DCL-1302 DCL-1303 DCL-1304 DCL-2254
具和照明器具及其它移动电设施，也可应用于机电产品的自动化检测线，自动生产线等，亦可用作厂矿、车
导线 Wires
Rated insulation voltage Ui VAC/DC 400/400 400/400 400/400 400/400 间、办公室等场所内固定数设母线槽，作借供电线路。
额定绝缘电压 Ui

过压类别/污染等级 Overvoltage category/pollution class 111/3 111/3 111/3 111/3
额定工作电压 Ue Rated working voltage Uo VAC 400 400 400 400 HX Safety power supply trolley bus device can be used for electric Hu Lu, electric gantry and bridge crane, pushing machine,
频率 Frequency Hz 50-60 50-60 50-60 50-60 storage facilities, portable electric tools and lighting fixtures and other mobile electric facilities, automatic detection line can also be used
额定电流1≈热额定电流 最大40℃和35℃，持续24小时以上 A 30 30 30 2×25
Rated current thermal rated current Max 40℃ and 35℃, lasting above 24 hours in mechanical and electrical products, automatic production lines, can also be used as a factory, workshop, office etc. place a fixed
导线阻抗，50Hz, 20℃导线温度时 number of busbar slot, as by the power supply line.
Wire resistance & reactance, 50Hz, 20℃ wire temperature
mΩ/m 5.79 5.79 5.79 4.56
电阻 Resistance R 20
mΩ/m 0.26 0.26 0.26 0.15
电抗 Reactance X 20
mΩ/m 5.80 5.80 5.80 4.56
阻抗 Resistance & reactance Z 20
故障时的导线阻抗 Wire resistance & reactance when breakdown R
mΩ/m 8.24 8.24 8.24 7.50
交流阻抗 AC resistance & reactance R F
mΩ/m 0.44 0.44 0.44 0.32
电抗 Reactance X F
mΩ/m 8.25 8.25 8.25 7.51
阻抗 Resistance & reactance Z F
零阻抗，根据 IEC 60 909、VDE 0102 标准测试
Zero resistance & reactance, test based on IEC 60 909 and VDE 0102 standard
相到 phase to N mΩ/m 24.24 24.24 24.24 18.59
电阻 Resistance R O
相到 phase to N mΩ/m 1.77 1.77 1.77 0.82
电抗 Reactance X O
相到 phase to N mΩ/m 24.30 24.30 24.30 18.61
阻抗 Resistance & reactance Z O
相到 phase to PE mΩ/m 12.00 12.00 12.00 13.49
电阻 Resistance R O
相到 phase to PE mΩ/m 1.80 1.80 1.80 0.82
电抗 Reactance X O
相到 phase to PE mΩ/m 12.13 12.13 12.13 13.52
阻抗 Resistance & reactance Z O
短路额定值 Short cut rated value
kA 2.4 2.4 2.4 3.0
额定峰值耐受电流 Rated peak withstand current I pk
额定短时耐受电流 Rated short-time withstand current I cw (t = 1s) kA 0.56 0.56 0.56 0.69
额定短时耐受电流 Rated short-time withstand current I cw (t = 0.1s) kA 1.6 1.6 1.6 2.0 主要技术指标
带电导线根数 Current-carrying wire quantity 2 2 2 2×4 The main technology index
导线横截面 Wire transverse section
L1,L2,L3 mm 2 3.2 3.2 3.2 4.0 使用环境： The use of the environment:
N mm 3.2 3.2 3.2 4.0 海拔高度≤2000m
PE(外壳shell) ≈ Cu mm 11 11 11 11 Elevation≤ 2000m
导线材质 Wire material Cu Cu Cu Cu 周围空气湿度< 90％ The humidity of the ambient air of < 90%
阻燃性 Fire-proof kWh/m 0.1 0.1 0.1 0.48 Install class III
2
最大热负荷，I 2 t 值 Max thermal load I 2 t value A sx10 3 310 310 310 470 安装类别Ⅲ类
Pollution level 4 ( general electric dust and gel state )
正常机械负荷时的固定间隔 Fixed interval for the normal mechanical load m 3 3 3 3 污染等级4级(一般导电粉尘和凝露状态) Vibration and shock: no violent vibration or foreign impact
插接单元 Connector unit 振动与冲击：无剧烈振动或异物撞击 This product complies with the Ministry of machinery
插接口 Connector port 每端每隔0.5m、1m或0.5m的偏差；最大16A Each end every 0.5m, 1m or 0.5m deviation, maximum is 16A 本产品符合：机械工业部行业标准J B/ industry: industry standard JB/T6391-1~2 " crane sliding
插接单元 Connector unit 3线制和5线制；有或无附装电缆；有或无熔断器座，8.5mm×31.5mm; gG型(IEC)和gL型(VDE)圆筒型快速熔断器。所有插接单元的
使用类别为AC-20B,IEC/EN 60 947-3。PE在连接时作为超前触头动作，在拔下分接插头时作为滞后触头动作。 T6391-1~2《起重机滑接输电装置技术条件》 power supply device technical conditions "
3 wires system and 5 wires system; with or without attached cable; with or without fuse protector base, 8.5mm * 31.5mm; gG type (IEC) and Gl type (VDE) cylinder quick fuse protector.
All the application type of connector are AC-20B, IEC/EN 60 947-3 PE working as lead contactor action when connected, working as lag action when disconnected.
端子容量 Terminal capacity 环境温度： Environment temperature:
名称 类型 L1,L2,L3 N PE Common type: -15℃- +55℃outdoor sunshade facilities
Name Category 最小值mm 2 最大值mm 2 最小值mm 2 最大值mm 2 最小值mm 2 最大值mm 2 普遍型：-15℃- +55℃室外应有遮阳设施
Minimum Maximum Minimum Maximum Minimum Maximum should be
进线单元 DCL-...-EA 2.5 6(f) 2.5 6(f) 2.5 6(f) 铝合金型：输电导管-40℃- 85℃ Aluminum alloy type: transmission conduit -40℃- 85℃
Incoming wiring unit 10(st,so) 10(st,so) 10(st,so) 橡胶密封闭带+80℃
终端单元 DCL-...-EE 2.5 6(f) 2.5 6(f) 2.5 6(f) Rubber seal with +80℃
Terminal unit 10(st,so) 10(st,so) 10(st,so) PVC密封盖+55℃
PVC sealing cover of +55℃
注：so = 实心线， st = 绞合线， f = 软线， 带线鼻子 集电器-40℃~105℃
Note：so =Solid wire， st = Stranded wire， f = Flexible wire with lug Collector -40℃~105℃

27 BUSWAY SERIES BUSWAY SERIES 28
