梯级式桥架 梯级式桥架
Ladder Tray Ladder Tray

梯级式水平三通 XQJ-T1-03 梯级式垂直凹弯通 XQJ-T1-05A
Ladder Type Horizontal T-jiont Cable Tray Mode XQJ-T1-03 Ladder Type Horizontal Concave Elbow Cable Tray Model XQJ-T1-05A

型 号 宽 度 高 度 L1 L2 备 注Remark 型 号 宽 度 高 度
Model width H Model width Height L 备 注Remark
T1-03-6-2 60 当H=60 T1-05A-6-2 60 360 当H=60
T1-03-10-2 200 100 800 500 H=100时， T1-05A-10-2 200 100 400 H=100时，
T1-03-15-2 150 每端各6只 T1-05A-15-2 150 450 每端各6只
T1-03-6-3 60 600 连接孔 T1-05A-6-3 60 360 连接孔 式 梯级
T1-03-10-3 300 100 900 when T1-05A-10-3 300 100 400 when
T1-03-15-3 150 H=60,H=100, T1-05A-15-3 150 450 H=60,H=100,
there will be
T1-03-6-4 60 T1-05A-6-4 60 360 there will be
L 6 connection 6 connection
T1-03-10-4 400 100 1000 700 holes at T1-05A-10-4 400 100 400
T1-03-15-4 150 each side. T1-05A-15-4 150 450 holes at
each side.
T1-03-6-5 60 当H=150 T1-05A-6-5 60 360
H 当H=150
T1-03-10-5 500 100 1100 800 时，每端各 T1-05A-10-5 500 100 400 时，每端各
T1-03-15-5 150 12只连接孔
B B T1-05A-15-5 150 450 12只连接孔
T1-03-6-6 60 T1-05A-6-6 60 360 when H=150,
L1 when H=150,
T1-03-10-6 600 100 1200 900 there will T1-05A-10-6 600 100 400 there will
T1-03-15-6 150 be 12 T1-05A-15-6 150 450 be 12
T1-03-6-8 60 connection T1-05A-6-8 60 360 connection
T1-03-10-8 800 100 1400 1100 holes at T1-05A-10-8 800 100 400 holes at
T1-03-15-8 150 each side T1-05A-15-8 150 450 each side
注：订货时，请注明是否带盖。 注：订货时，请注明是否带盖。
Note:with cover or not shall be identified when ordering. Note:with cover or not shall be identified when ordering.
梯级式水平四通 XQJ-T1-04 梯级式垂直凸弯通 XQJ-T1-05B
Ladder Type Horizontal Cross Joint Cable Tray Model XQJ-T1-04 Ladder Type Vertical Convex Elbow Cable Tray Model XQJ-T1-05B

型 号 宽 度 高 度 L 备 注Remark 型 号 宽 度 高 度 L 备 注
Model width Height Model width Height Remark
T1-04-6-2 60 800 当H=60 T1-05B-6-2 60 360 当H=60
T1-04-10-2 200 100 H=100时， T1-05B-10-2 200 100 400 H=100时，
T1-04-15-2 150 800 每端各6只 T1-05B-15-2 150 550 每端各6只
T1-04-6-3 60 900 连接孔 T1-05B-6-3 60 360 连接孔
T1-04-10-3 300 100 when T1-05B-10-3 300 100 400 when
H=60,H=100,
T1-04-15-3 150 900 H=60,H=100, T1-05B-15-3 150 550 there will be
T1-04-6-4 60 1000 there will be T1-05B-6-4 60 360 6 connection
T1-04-10-4 400 100 6 connection T1-05B-10-4 400 100 400 holes at
T1-04-15-4 150 1000 holes at T1-05B-15-4 150 550 each side.
each side.
T1-04-6-5 60 1100 当H=150 T1-05B-6-5 60 360 当H=150
T1-04-10-5 500 100 T1-05B-10-5 500 100 400 时，每端各
H 时，每端各
T1-04-15-5 150 1100 T1-05B-15-5 150 550 12只连接孔
12只连接孔
T1-04-6-6 60 T1-05B-6-6 60 360 when H=150,
B B 1200 when H=150,
T1-04-10-6 600 100 there will
L1 T1-05B-10-6 600 100 400 there will
T1-04-15-6 150 1200 be 12 T1-05B-15-6 150 550 be 12
T1-04-6-8 60 connection T1-05B-6-8 60 360 connection
T1-04-10-8 800 100 1400 holes at T1-05B-10-8 800 100 400 holes at
T1-04-15-8 150 1400 each side T1-05B-15-8 150 550 each side
注：订货时，请注明是否带盖。 注：订货时，请注明是否带盖。
Note:with cover or not shall be identified when ordering. Note:with cover or not shall be identified when ordering.
