QKSC 树脂绝缘干式铁心启动电抗器
Series resin insulation dry-type core shunt reactor

▁ 产品结构 /product structure

QKSC 干式铁芯起动电抗器的铁芯采用优质进口冷轧硅钢片，芯柱由多个气隙分成均匀小段，气隙采用环氧板作为隔绝，并采用高温高强
粘接剂，以保证气隙在电抗器运行时不发生变化；
铁芯端面采用优质硅钢片端面胶，使硅钢片牢固地结合在一起，大大减小了运行中的噪音，并具有较好的防腐蚀性；

线圈绕包式结构，线圈主绝缘采用玻璃纤维浸渍环氧树脂，热烘固化后在真空下浸以耐高温绝缘漆，该线圈不但绝缘性能好，而且机械强
度高，能耐受电机启动时的大电流冲击和冷热冲击而不开裂。
The core of QKSC dry core starting reactor adopts high-quality imported cold-rolled silicon steel sheet, and the core column is divided into
small uniform segments by multiple air gaps. The air gap is isolated by epoxy plate, and the high temperature and high strength adhesive is
used to ensure that the air gap does not change during the operation of the reactor.
The end face of iron core is made of high quality silicon steel sheet end face glue, which makes the silicon steel sheet firmly combined, greatly
reduces the noise in operation, and has good corrosion resistance;
The main insulation of the coil is glass fiber impregnated epoxy resin. After hot drying and curing, the coil is dipped under vacuum to withstand
high temperature insulation paint. The coil is not only insulated with good performance, but also has high mechanical strength.

▁ 订货基本数据 /ordering the basic data

请在订货时以书面形式提出以下参数和技术要求： Please put forward the following parameters and technical requirements in
1、电抗器的额定容量； writing when ordering:

2、系统额定电压和频率； 1. Rated capacity of the reactor;
2. Rated voltage and frequency of the system;
3、电容器端电压
3. Capacitor terminal voltage
4、额定电抗率或电抗；
4. Rated reactance or reactance;
5、额定电流及最大连续电流；
5. Rated current and maximum continuous current;
6、动、热稳定电流及持续时间；
6. Dynamic and thermal stable current and duration;
7、每次启动运行时间，连续启动运行次数
7. Running time of each startup and running times of continuous startup
8、启动冷却周期； 8. Start the cooling cycle;
9、使用条件 ( 户内 ) 9. Conditions of use (indoor)
10、其它特殊要求 10. Other special requirements
