INSULATING TERMINALS SERIES INSULATING TERMINALS SERIES

> >
2
2
:2.5~4mm ( 14~12) Imax=37A :6~10mm ( 8) Imax=62A
DIMENSION
DIMENSION d
B L F E D d ITEM NO . B L F E D
ITEM NO . d2 mm mm mm mm mm mm
d2 mm mm mm mm mm
RNB8-4S #8 4.3mm 8.8 23.8 9.3
RNB3.5-4 #8 4.3mm 8.0 18.0 7.7
RNB8-4L #8 4.3mm 12.0 23.8 9.3
RNB3.5-5S #10 5.3mm 8.0 18.0 7.7 RNB8-5S #10 5.3mm 8.8 23.8 11.1
RNB3.5-5M #10 5.3mm 9.5 19.8 8.3 RNB8-5M #10 5.3mm 12.0 23.8 9.3
RNB3.5-5L #10 5.3mm 12.0 21.4 7.7 6.0 5.0 3.0 RNB8-5L #10 5.3mm 15.0 29.8 13.8 8.5 7.2 4.5
RNB8-6S 1 /4 6.5mm 12.0 23.8 9.3
RNB3.5-6 1 /4 6.5mm 12.0 21.4 7.7
RNB8-6L 1 /4 6.5mm 15.0 29.8 13.8
RNB3.5-8 5/16 8.4mm 15.0 27.0 13.5
RNB8-8 5/16 8.4mm 15.0 29.8 13.8
RNB3.5-10 3/8 10.5mm 15.0 27.0 13.5 RNB8-10 3/8 10.5mm 15.0 29.8 13.8
RNB8-12 1 /2 13.0mm 20.0 33.5 15.0
2
:10~16mm ( 6) Imax=88A
2
:4~6mm ( 12~10) Imax=48A DIMENSION
B L F E D d
DIMENSION ITEM NO .
B L F E D d D2 mm mm mm mm mm mm
ITEM NO . RNB14-4 #8 4.3mm 12.0 29.8 13.3
d2 mm mm mm mm mm
RNB14-5 #10 5.3mm 12.0 29.8 13.3
RNB5.5-3.5 #6 3.7mm 7.2 15.7 5.9
RNB14-6S 1 /4 6.5mm 12.0 28.8 13.3
B
I L RNB5.5-4S #8 4.3mm 7.2 15.7 5.9 RNB14-6L 1 /4 6.5mm 16.0 32.8 13.3 10.5 9.0 5.8 I
d2
RNB5.5-4L #8 4.3mm 9.5 19.8 8.3 RNB14-8 5/16 8.4mm 16.0 32.8 14.5
RNB5.5-5 #10 5.3mm 9.5 19.8 8.3 RNB14-10 3/8 10.5mm 16.0 32.8 14.5
F 6.8 5.6 3.4 RNB14-12 1 /2 13.0mm 22.0 41.0 19.5
RNB5.5-6 1 /4 6.5mm 12.0 23.0 12.0
d
D E
RNB5.5-8 5/16 8.4mm 15.0 28.0 13.7
RNB5.5-10 3/8 10.5mm 15.0 28.0 13.7 L B
2
RNB5.5-12 1 /2 13.0mm 19.2 32.4 16.0 d2 :16~25mm ( 4) Imax=115A
DIMENSION
F
d ITEM NO . B L F E D d
D E D2 mm mm mm mm mm mm
RVB22-5S #10 5.3mm 12.2 33.2 14.5
RVB22-5L #10 5.3mm 16.5 33.7 13.5 Insulating terminals series
RVB22-6S 1 /4 6.5mm 12.2 33.2 14.5
RVB22-6L 1 /4 6.5mm 16.5 33.7 13.5
RVB22-8 5/16 8.4mm 16.5 33.7 135. 12.0 11.5 7.7
Insulating terminals series
RVB22-10 3/8 10.5mm 16.5 33.7 13.5
RVB22-11 7/16 11.5mm 22.0 42.5 19.5
RVB22-12 1 /2 13.0mm 22.0 42.5 19.5
2
:25~35mm ( 2) Imax=160A
DIMENSION
B L F E D d
ITEM NO .
d2 mm mm mm mm mm mm
RVB38-5 #10 5.3mm 15.3 39.0 18.3
RVB38-6 1 /4 6.5mm 15.3 39.0 18.3
RVB38-8S 5/16 8.4mm 15.3 39.0 18.3
RVB38-8L 5/16 8.4mm 22.0 42.7 17.7 14.0 13.3 9.4
RVB38-10S 3/8 10.5mm 15.3 39.0 18.3
RVB38-10L 3/8 10.5mm 22.0 42.7 17.7
RVB38-11 7/16 11.5mm 22.0 42.7 17.7
RVB38-12 1 /2 13.0mm 22.0 42.7 17.7
