INSULATING TERMINALS SERIES INSULATING TERMINALS SERIES

> > (TU )
2
2
:0.5~1.5mm ( 22~16) Imax=19A :0.5~1.5mm ( 22~16) Imax=19A
DIMENSION DIMENSION
B L F H D B L F E D d
ITEM NO . COLOR ITEM NO .
d2 mm mm mm mm mm d2 mm mm mm mm mm mm
SV1.25-3 #4 3.2mm 5.7 21.2 6.5 SNB1.25-3 #4 3.2mm 5.7 16.0 6.5
SV1.25-3.5S #6 3.7mm 5.7 21.2 6.5 SNB1.25-3.5S #6 3.7mm 5.7 16.0 6.5
SV1.25-3.5L #6 3.7mm 6.4 21.2 6.5 SNB1.25-3.5L #6 3.7mm 6.4 16.0 6.5
SV1.25-4S #8 4.3mm 6.4 21.2 6.5 SNB1.25-4S #8 4.3mm 6.4 16.0 6.5
SV1.25-4M #8 4.3mm 7.2 21.2 6.5 SNB1.25-4M #8 4.3mm 7.2 16.0 6.5
SV1.25-4L #8 4.3mm 8.1 21.2 6.5 10.0 4.3 SNB1.25-4L #8 4.3mm 8.1 16.0 6.5 4.8 3.4 1.7
red
SV1.25-5S #10 5.3mm 8.1 21.2 6.5 SNB1.25-5S #10 5.3mm 8.1 16.0 6.5
SV1.25-5L #10 5.3mm 9.5 21.2 6.5 SNB1.25-5L #10 5.3mm 9.5 16.0 6.5
SV1.25-6S 1 /4 6.5mm 9.5 21.2 6.5 SNB1.25-6S 1 /4 6.5mm 9.5 16.0 6.5
SV1.25-6L 1 /4 6.5mm 12.0 27.2 11.0 SNB1.25-6L 1 /4 6.5mm 12.0 22.0 11.0
SV1.25-8 5/16 8.5mm 14.0 29.0 12.5 SNB1.25-8 5/16 8.4mm 14.0 23.5 12.5

2
:1.5~2.5mm ( 16~14) Imax=27A
DIMENSION 2
:1.5~2.5mm ( 16~14) Imax=27A
B L F H D
ITEM NO . COLOR
d2 mm mm mm mm mm DIMENSION
SV2-3 #4 3.2mm 5.7 21.2 6.5 B L F E D d
ITEM NO .
SV2-3.5S #6 3.7mm 5.7 21.2 6.5 d2 mm mm mm mm mm mm
B
6.5
#6
SV2-3.5L
21.2
3.7mm
6.4
I SV2-4S #8 4.3mm 6.4 21.2 6.5 L d2 SNB2-3 #4 3.2mm 5.7 16.0 6.5 I
SNB2-3.5S
5.7
16.0
6.5
#6
3.7mm
SV2-4M #8 4.3mm 7.2 21.2 6.5 SNB2-3.5L #6 3.7mm 6.4 16.0 6.5
SV2-4L #8 4.3mm 8.1 21.2 6.5 10.0 4.9 SNB2-4S #8 4.3mm 6.4 16.0 6.5
blue
SV2-5S #10 5.3mm 8.1 21.2 6.5 d F SNB2-4M #8 4.3mm 7.2 16.0 6.5
SV2-5L #10 5.3mm 9.5 21.2 6.5 D E SNB2-4L #8 4.3mm 8.1 16.0 6.5 4.8 4.1 2.3
SV2-6S 1 /4 6.5mm 9.5 21.2 6.5 SNB2-5S #10 5.3mm 8.1 16.0 6.5
SV2-6L 1 /4 6.5mm 12.0 27.2 11.0 SNB2-5L #10 5.3mm 9.5 16.0 6.5
B
L d2
SV2-8 5/16 8.5mm 14.0 29.0 12.5 SNB2-6S 1 /4 6.5mm 9.5 16.0 6.5
SNB2-6L 1 /4 6.5mm 12.0 22.0 11.0
SNB2-8 5/16 8.4mm 14.0 23.5 12.5
F
2
:2.5~4mm ( 14~12) Imax=37A
D
H
DIMENSION Insulating terminals series
B L F H D
ITEM NO . COLOR
d2 mm mm mm mm mm
SV3.5-3 #4 3.2mm 5.7 24.8 7.0
SV3.5-4 #8 4.3mm 8.0 24.8 7.0
Insulating terminals series
12.5 6.2
SV3.5-5 #10 5.3mm 8.0 24.8 7.0 black
SV3.5-6 1 /4 6.5mm 12.0 28.0 12.1
2
:4~6mm ( 12~10) Imax=48A
DIMENSION
B L F H D
ITEM NO . COLOR
d2 mm mm mm mm mm
SV5.5-3.5 #6 3.7mm 8.3 25.2 7.5
SV5.5-4S #8 4.3mm 8.3 25.2 7.5
SV5.5-4L #8 4.3mm 9.0 25.2 7.5
SV5.5-5 #10 5.3mm 9.0 25.2 7.5 12.5 6.7
yellow
SV5.5-6S 1 /4 6.5mm 9.0 25.2 7.5
SV5.5-6L 1 /4 6.5mm 12.0 31.2 12.0
SV5.5-8 1 /4 8.4mm 14.0 30.0 11.5
PVC SD
93 ZHUCHENG ELECTRICAL ZHUCHENG ELECTRICAL 94
