> Raised floor trunking system techincal data

Epoxy Coated Trunking
Trunkings are supplied in 2440mm lengths as a standard with The frame, which is also reversible, incorporates a unique ratchet
conduit dnockouts on the cover. The service boxes are also pro- system and is designed to self-adjust to any normal floor finish
vided with conduit knock outs. Flexible conduits are used to con- thicknes. The frame is secured by hand operated ratchet bars
nect the trunking to the service box. that provide quick efficient installation and removal without the
The trunkin can be supplied in single and multi-compartments needs for tools.
with internal segregation. These are available in 7 basic widths of
75mm, 100mm, 150mm, 200mm, 225mm, 300mm and 450mm. To remove the carpet frame, the ratchet bars on the opposite
Raised Floor Trunking is supplied epoxy coated over electro- sides of the frame are pulled towards the center of the box re-
galvanised sheet steel as standard. leasing the grip and allowing the frame to be lifted clear.
The epoxy coated trunking is done in orange The accessory plates within the floor outlet box can be removed
Please colour, thus ensuring high visibility under the from above without baving to remover the entire floor outlet box.
Note raised floor when installed panels are lifted
off for maintenance purposes.
A wide range of power, telecommunication and data accessory
plated are available. Thes plates are inter-changeable, allowing
UPVC Raised floor trunking any combination to the precise requirements are unknown.
Rectangular uPVC ducts used for
Raised floor applications are supplied The floor outlet boxes are supplied with an adjustable mounting
in 2.9mtrs. Each service can be
contaned in separate trunkings(two bracket fixed to each of the two short sides.
or three as the need may be). To fa-
cilitate ease of access the covers are
clip on type. Due to its inherent
characteristice, uPVC trunkings are
non-corrosive and easy to work with.

Polyamide Raised Floor Service Box
The polyamide service box incorporates
many innovative features designed to
speed up installation and provide the
end-user with a safe and easy-to-use
product.
Floor outlets boxes ar normally secured
within panels that can be re-located any where within an access floor.
The ‘ snap-in’ trap, incorporating a steel reinforcing plate, is revers-
ible and readily detaches from the frame when accidentally kicked or
knocked. The trap is recessed to accommodate upto 7mm thickness
of carpet or similar floor finishes. A retractable handle provides ac-
cess to the interior of the floor box. The floor outlet boxes are sup-
plied complete with textured, easy-to-clean frame and lid.
Cables are guided by cable retainers through generous cable outlets
that open automatically and lock into position when cables are present.
Detachable cable retainers are mounted on the side of the frame to
guide cables safely through the outlets in the lid.

EXPLODED VIEW OF POLYAMIDE
RAISED FLOOR SERVICE BOX
