气动工具
 D D Air Filtration Combination



 空压冲床 Air press punch  空压开关 Air press switch



























 印花机  精密空压冲床                                         空压开关                                                空压开关
 印花机用途 Purpose of  Printing machine
                                                         2 Polerating
 用于印花、烫金等工业。此冲床具有单动、单定时回复、连动等操作方式。
                           最底闭合压力       最高断开压力       最高断开压力           1H          3PH               DC
 The machine using printing, bronzing and so on industries. This punch is provided with thesingle action, single fixed time reply, continuous action and so on operation modes.  型号 Type  2  2  2
                           kgf/cm  Min on  kgf/cm  Max off  kgf/cm  Max off  120V  240V  240V  600V  32V  120V  240V
 精密空压冲床用途 Purpose of Precision air-pressure punch  PS10-1H  2.5  10.5  2.0-2.9  1-HP  2HP  3HP  ……  1-HP    -HP    -HP
                                                                                                           1
                                                                                             1
                                                                                                    1
                                                                  1
                                                                                                    4
                                                                                             4
                                                                  2
                                                                                                           4
                                                                  1
                                                                                             1
                                                                                                           1
                                                                                                    1
 B04-0.5型气动型全自动台式精密压力机，属小型精密压力设备，适合电子、仪表、钟表、照相机、首饰、小五金及服装、鞋帽业，可对薄板、条  PS10-4H  2.5  10.5  2.0-2.9  1-HP  2HP  3HP  ……  1-HP    -HP    -HP
                                                                                                           4
                                                                                             4
                                                                  2
                                                                                                    4
 料、卷材、进行剪切、冲孔、落料、弯曲、铆合等工序。适用有色金属、塑料件的加工。本机生产效率高、精度好、操作灵敏简便，应用广泛。  PS17-1H  2.8  17.6  2.1-4.4  2HP  2HP  5HP  5HP  2HP  2HP  2HP
 B04-0.5 pneumatic full auto table type precision pressure gauge, is mini precision press equipment, suitable for electronic, instrument , watch, camera, ornaments,
 hardware and garment, shoes and cap industries. It can cut ,punch and feed material, bend and rivet thin board, strip material, roll material and so on. It is used for
 processing of non-ferrous metal, plastice. This machine has high productive efficiency, fine precision, simple and sensitive operation, wide usage.  油管 Oit tube  空压夹具 Air press tongs
 精度 Precision
 精度项目  Precision item  允差 QB04+0.5
 工作台台面的平面度 Planeness of work table table-board  0.030
 滑块下平面的平面度 Planeness of dieblock plane  0.010
 摸柄孔对滑块下平面的垂直度 Verticality between handle hole and dieblock lower plance  0.025
 0.020
 滑块下平面对工作台台面的平行度   左右 Left Right
 Parallelism between dieblock plane and work table table-board  前后 Front Back  0.025
 0.010
 滑块行程对工作台台面的垂直度   左右 Left Right
 The verticality between dieblock stage and work tabel table-board  前后 Front Back  0.015
 技术参数 Main technical partameters
 型号 Mode  单位  JB04-0.5
 公称力 Nominal force  KN  5(0.5)
 滑块行程 Dieblock stage  mm  30                  OEL01\02\03\04油管                                           空压夹具
 气缸直径 Air cylinder diameter  mm  100
          油管用途 Purpose of   Oit tube
 最大封闭高度 Max sealed highness  mm  205
          适用于机床、液压机械、数控机床作油、水冷却系统配用，该产品通过手工装配，可任意调节使用长度、喷嘴直径大小圆扁互换、方向随意可转，具
 立柱中心距离 Column center distance  mm  140
 摸柄孔直径 Handle hole diameter  mm  18×38  有外形色彩美观、油量大、不导电、耐腐蚀、耐高温等特点。
 工作台面尺寸(左右×前后) Work table dimension (left and right×front and rear)  mm  257×178  It is suitable for using machine tool, hydraulic pressure machine, digital control machine tool oil, water-cooling pump system. The ervice length,
 气缸工作压力 Air cylinder working pressure  Kg/cm 2  1  2  3  4  nozzle diameter s size being circle or flat, the direction all can be adjusted at will through hand assemble. It has many characteristics of colored
 活塞推动力 Piston motive force  Kg  78.5  157  235.6  314.1  and beautiful at outside, big oil quantity, failed to conduct, withstand corrosion, high temperature and so on etc.
 气缸工作压力 Air cylinder working pressure  Kg/cm 2  5  6  7  8
          空压夹具技术参数 Main technical tongs of Air press tongs
 活塞推动力 Piston motive force  Kg  392.6  471.2  549.7  628.3
 外形尺寸(长×宽×高度) Overall dimension(L×W×H)  mm  345× 298× 576  使用流体 Fluid applied   空气 Air
 电压/耗电量 Voltage/ power consumption  AC/DC  220V / 3.0W  工作压力范围 Working applied range  8~10kgf/cm 2
 机床重量 Punch heavy  kg  41  工作温度范围 Working temp range                            0~70℃
