气动工具
D D Air Filtration Combination

空压冲床 Air press punch 空压开关 Air press switch

印花机 精密空压冲床 空压开关 空压开关
印花机用途 Purpose of Printing machine
2 Polerating
用于印花、烫金等工业。此冲床具有单动、单定时回复、连动等操作方式。
最底闭合压力 最高断开压力 最高断开压力 1H 3PH DC
The machine using printing, bronzing and so on industries. This punch is provided with thesingle action, single fixed time reply, continuous action and so on operation modes. 型号 Type 2 2 2
kgf/cm Min on kgf/cm Max off kgf/cm Max off 120V 240V 240V 600V 32V 120V 240V
精密空压冲床用途 Purpose of Precision air-pressure punch PS10-1H 2.5 10.5 2.0-2.9 1-HP 2HP 3HP …… 1-HP -HP -HP
1
1
1
1
4
4
2
4
1
1
1
1
B04-0.5型气动型全自动台式精密压力机，属小型精密压力设备，适合电子、仪表、钟表、照相机、首饰、小五金及服装、鞋帽业，可对薄板、条 PS10-4H 2.5 10.5 2.0-2.9 1-HP 2HP 3HP …… 1-HP -HP -HP
4
4
2
4
料、卷材、进行剪切、冲孔、落料、弯曲、铆合等工序。适用有色金属、塑料件的加工。本机生产效率高、精度好、操作灵敏简便，应用广泛。 PS17-1H 2.8 17.6 2.1-4.4 2HP 2HP 5HP 5HP 2HP 2HP 2HP
B04-0.5 pneumatic full auto table type precision pressure gauge, is mini precision press equipment, suitable for electronic, instrument , watch, camera, ornaments,
hardware and garment, shoes and cap industries. It can cut ,punch and feed material, bend and rivet thin board, strip material, roll material and so on. It is used for
processing of non-ferrous metal, plastice. This machine has high productive efficiency, fine precision, simple and sensitive operation, wide usage. 油管 Oit tube 空压夹具 Air press tongs
精度 Precision
精度项目 Precision item 允差 QB04+0.5
工作台台面的平面度 Planeness of work table table-board 0.030
滑块下平面的平面度 Planeness of dieblock plane 0.010
摸柄孔对滑块下平面的垂直度 Verticality between handle hole and dieblock lower plance 0.025
0.020
滑块下平面对工作台台面的平行度 左右 Left Right
Parallelism between dieblock plane and work table table-board 前后 Front Back 0.025
0.010
滑块行程对工作台台面的垂直度 左右 Left Right
The verticality between dieblock stage and work tabel table-board 前后 Front Back 0.015
技术参数 Main technical partameters
型号 Mode 单位 JB04-0.5
公称力 Nominal force KN 5(0.5)
滑块行程 Dieblock stage mm 30 OEL01\02\03\04油管 空压夹具
气缸直径 Air cylinder diameter mm 100
油管用途 Purpose of Oit tube
最大封闭高度 Max sealed highness mm 205
适用于机床、液压机械、数控机床作油、水冷却系统配用，该产品通过手工装配，可任意调节使用长度、喷嘴直径大小圆扁互换、方向随意可转，具
立柱中心距离 Column center distance mm 140
摸柄孔直径 Handle hole diameter mm 18×38 有外形色彩美观、油量大、不导电、耐腐蚀、耐高温等特点。
工作台面尺寸(左右×前后) Work table dimension (left and right×front and rear) mm 257×178 It is suitable for using machine tool, hydraulic pressure machine, digital control machine tool oil, water-cooling pump system. The ervice length,
气缸工作压力 Air cylinder working pressure Kg/cm 2 1 2 3 4 nozzle diameter s size being circle or flat, the direction all can be adjusted at will through hand assemble. It has many characteristics of colored
活塞推动力 Piston motive force Kg 78.5 157 235.6 314.1 and beautiful at outside, big oil quantity, failed to conduct, withstand corrosion, high temperature and so on etc.
气缸工作压力 Air cylinder working pressure Kg/cm 2 5 6 7 8
空压夹具技术参数 Main technical tongs of Air press tongs
活塞推动力 Piston motive force Kg 392.6 471.2 549.7 628.3
外形尺寸(长×宽×高度) Overall dimension(L×W×H) mm 345× 298× 576 使用流体 Fluid applied 空气 Air
电压/耗电量 Voltage/ power consumption AC/DC 220V / 3.0W 工作压力范围 Working applied range 8~10kgf/cm 2
机床重量 Punch heavy kg 41 工作温度范围 Working temp range 0~70℃
77 产品选型手册 产品选型手册 78
Products Manual For Technical Pattern Selection Products Manual For Technical Pattern Selection
