3. 使用环境条件 5. 结构简介

Service Conditions Construction

开关设备按GB3906中的铠装式金属封闭开关设备而设
正常环境条件 Normal service conditions 计。整体是由柜体和中置式可抽出部件(即手车)两大部分组

● 周围空气温度 ● Ambient temperature 成。柜体分四个单独的隔室，外壳防护等级为IP4X，各小室间 A
- upper limit +40℃ D
- 上限：+40℃ - lower limit -10 ℃ 和断路器室门打开时防护等级为IP2X。具有架空进出线、电缆
- 下限：-10℃ ● Altitude 进出线及其它功能方案，经排列、组合后能成为各种方案形式
- 1000m 的配电装置。本开关设备可以从正面进行安装调试和维护，因
● 海拔
● Relative humidity 此它可以背靠背组成双重排列和靠墙安装，提高开关设备的安
- 1000m - daily mean not greater than 95% 全性、灵活性，减少了占地面积。 B
- monthly mean not greater than 90%
● 相对环境湿度
● Earthquake The switchgear,designed in accordane with GB 3906,is composed of cubicle
- 日平均不大于95%，月平均不大于90% - Earthquake intensity not exceeding 8 and mid-positioned withdrawable part(truck).The cubicle is separated into
four compartments.The degree of protection of enclosure is IP4X and the
degree of protection is IP2X between compartments or opened circuit breaker
doors.The trucks are provided with such functions as overhead incoming and
特殊工作条件 Special service conditions outgoing lines,cable incoming and outgoing as well as others,which can form C
the distribution equipment with different schemes after arrangement and
在超过规定的正常的环境条件下使用时，由用户和 If the switchgear is used in the severe conditions,an combination.The switchgear is installed,commissioned and maintained from
agreement must be made between customer and the front,so it can be con gurated back to back or be installed against the wall.
制造厂协商。 manufacturer. In this way the switchgear has better safety and exibility,and less space area.
A 母线室 A Busbar compartment
外壳 B 断路器手车室 B Circuit breaker truck compartment
C 电缆室 C Cable compartment
4. 主要技术参数 开关设备的外壳选用敷铝锌薄钢板，经CNC机床加工，并 D 继电器仪表室 D Relays and meters compartment
Main Technical Parameters 采取多重折边工艺。这样使整个柜体不仅具有精度高、很强的
抗腐蚀与抗氧化作用，而且由于采用多重折边工艺，使柜体比 开关设备结构示意图
The sectional view is shown
其它同类 设备柜体整体重量轻、机械强度高、外形美观。柜体
额定电压(kV) / Rated voltage (kV) 12 采用组装式结构，用拉铆螺母和高强度的螺栓联接而成。这样
工频耐受电压(kV) / Power frequency withstand voltage (kV) 42 ( 1min ) 使加工生产周期短、零部件通用性强、占地面积少，便于组织
冲击耐受电压(kV) / Impulse withstand voltage (kV) 75 生产。
额定频率 / Rated frequency 50/60Hz
Enclosure
额定电流(A) / Rated current (A) 630~4000
The switchgear enclosure selects the Al-Zn sheet steel processed by CNC
额定热稳定电流(kA 4s) / Rated short time withstand current (kA 4s) 25~40 machining stool with multiple bending technique adopted.In this way the
cubicle body is of high accuracy,strong corrosion resistance and inoxidation.
额定动稳定电流(kA) / Rated peak withstand voltage (kA) 63~100
Further more it has lighter weight,highter mechanism strength and more
额定短路开断电流(kA) / Rated short circuit breaking current (kA) 25~40 beautiful appearance than other similar ones.the body is built up in
额定短路开合电流(kA) / Rated short circuit making current (kA) 63~100 construction and jointed with bolts and nuts so that the production cycle
is shortened,the part generaliztion raised,the space area reduced and the
分合闸和辅助回路的额定电压 (V) 直流(DC): 24 , 30 , 48 , 60 , 110 , 220 production procedure optimized.
Rated voltage of open, close and auxiliary circuits (V) 交流(AC): 110 , 220
防护等级 / Degree of protection IP4X 隔室
宽 Wide：650 , 800 , 1000
开关设备主要电气元件都有其独立的隔室。即：断路器手
柜体尺寸（W× D ×H）/ Dimensions 高 High：2250
车室、母线室、电缆室、继电器仪表室。各隔室间防护等级都
深（含门）Deep (with door) ：1400 , 1650
达到IP2X;除继电器室外，其它三隔室都分别有其泄压通道。由
于采用了中置式形式，电缆室位置大大增加，因此设备可接多
路电缆。

Compartment
The main electrical components and devices used in the switchgear have their
independent compartments such as circuit breaker compartment,busbar
compartment,cable compartment and metering compartment.The degree of
protection between compartments is up to IP2X.To the exclusion of metering
compartment,three other compartments are provided with relief channels.
Connection of multiple cables in the bigger compartment space is resulted
from the truck's mid-position.
