Outdoor assembled substation (European)

概述 Overview

FZBW-40.5 系列装配式变电站是高压 35kV, 低压侧 40kV 三相交流 50Hz 户外成套变配电设备，广泛应用于城市、乡镇、道路、工厂及油田、矿山、码
头等场所，也适用于一些大、中型建筑工地，作为接受、转换和分配电能之用，具有成套性强、体枳小、安装使用方便、运行维护简单、造价低、综合自动
化程度高度、运行安全可靠等特点。装配式变电站符合以下国家标准 : GB/T17467-1998 高压、低压装配式变电站、GB1985-2004 高压交流隔离开关和
接地开关、GB/T3309-1989 高压开关设备常温下的机械试验、GB30906-19913 ～ 35kV 交流金属封闭式开关设备、GB/T11022-1989 高压开关设备
和控制设备标准的共用技术要求、GB/16927.1-1997 高电压试验技术第一部分：一般试验要求。
FZBW-40.5 series assembled substation is a high-voltage 35kV, low-voltage side 40kV three-phase AC 50Hz outdoor complete set of
power distribution equipment, widely used in cities, towns, roads, factories and oil fields, mines, docks and other places, also suitable for
some large, Medium-sized construction sites, as a means of receiving, converting and distributing electrical energy, have the characteristics
of strong set, small body size, convenient installation and use, simple operation and maintenance, low cost, high comprehensive automation
and safe and reliable operation. The combined substation meets the following national standards: GB/T17467-1998 high voltage, low voltage
prefabricated substation, GB1985-2004 high voltage AC disconnector and grounding switch, GB/T3309-1989 high voltage switchgear
mechanical test at room temperature, GB30906-19913~ Common technical requirements for 35kV AC metal-enclosed switchgear, GB/
T11022-1989 high-voltage switchgear and control equipment, GB/16927.1-1997 high voltage test technology Part 1: General test
requirements.
型号及含义 Model and meaning
FZ B W □ - □ / 35 □
低压侧额定电压（kV） Low voltage side rated voltage (kV)
高压侧额定电压（kV） High voltage side rated voltage (kV)
变压器容量（kVA） Transformer capacity (kVA)
设计序号 Design Number
户外 outdoor
变电站 Substation
装配式 Assembled
