AC PLUG PINS AND PLUG INSERTS

>

D
T1 t W
T
L
L
W E
t

(Wire Range) (Size) (mm) Q`ty/reel
(Part No.) (Material)
mm 2 AWG# T T1 t D E L W
ER63201G-4 0.75-1.5 18-16 1.5 0.65 1.0 3.2 18.2 29.0 6.3 -
Brass
G ER63202G-4 0.75-1.5 18-16 1.6 0.65 1.0 3.9 18.0 29.0 6.3 -

D W1
T1
W2
T
L
E
t

(Wire Range) (Size) (mm)
Q`ty/reel
(Part No.) (Material)
mm 2 AWG# T T1 t D E L W1 W2
ER63301G-4 0.75-1.5 18-16 1.6 1.2 0.5 3.95 19.0 29.0 6.3 8.0 -
Brass
Ac plug pins and plug inserts
ER63302G-4 0.75-1.5 18-16 1.5 0.75 0.65 3.9 17.8 29.0 6.3 8.0 -

D
D
T1 t T1 t
T T
W1
E L E L
W2
W1

(Wire Range) (Size) (mm)
Q`ty/reel
(Part No.) (Material)
mm 2 AWG# T T1 t D E L W
ER63401G-1 0.75-1.5 18-16 1.5 1.0 0.5 3.2 19.0 29.0 6.3 -
Brass
ER63501G-1 0.75-1.5 18-16 1.5 1.0 0.5 3.0 18.5 28.5 6.3 8.0
