E E Auxiliary Component
辅助元件

快拧接头 Fast wring coupler 卡套接头 Brass sleeve tube fittings

KLU-快拧直通 技术说明 Technique explain KTU-卡套直通 技术说明 Technique explain
型号 Type 特点： 采用旋转锁母，能防止软管脱落 型号 Type 特点： 采用旋转锁母，能防止软管脱落
KLU-4 基本材料：铜 KTU-4 基本材料：铜
KLU-6 最高使用压力：1.0MPa(10.2kgf/cm ) KTU-6 最高使用压力：1.0MPa(10.2kgf/cm ) 2
2
KLU-8
2
保证耐压力：7.0MPa(71.4kgf/cm ) KTU-8 保证耐压力：7.0MPa(71.4kgf/cm ) 2
KLU-10 KTU-10
可用于真空系统(真空压力0.1Torr以下) 可用于真空系统(真空压力0.1Torr以下)
KLU-12
适用软管材料：尼龙及PU软管 KTU-12 适用软管材料：尼龙及PU软管
Chatacteristic: it can avoid soft tube drop out being adopting rotation locking female. Chatacteristic:it can avoid soft tube drop out being adopting rotation locking female.
Basic material: copper Basic material:copper
Max using pressure: 1.0MPa(10.2kgf/cm ) 2 Max using pressure:1.0MPa(10.2kgf/cm ) 2
2
2
Guaranteed compression resistance: 7.0MPa(71.4kgf/cm ) Guaranteed compression resistance:7.0MPa(71.4kgf/cm )
It can be used vacuum system(vacuum pressure 0.1T or below) It can be used vacuum system(vacuum pressure 0.1T or below)
Applicable soft tube: nylon and PU tube. Applicable soft tube: nylon and PU tube.
KLC-快拧螺纹直通 KLL-快拧螺纹二通 KTC-卡套螺纹直通 KTL-快拧螺纹二通
型号 Type 型号 Type 型号 Type 型号 Type
KLC4-M5 KLC8-03 KLL4-M5 KLL8-03 KTC4-M5 KTC8-03 KTL4-M5 KTL8-03
KLC4-01 KLC8-04 KLL4-01 KLL8-04 KTC4-01 KTC8-04 KTL4-01 KTL8-04
KLC4-02 KLC10-01 KLL4-02 KLL10-01 KTC4-02 KTC10-01 KTL4-02 KTL10-01
KLC6-M5 KLC10-02 KLL6-M5 KLL10-02 KTC6-M5 KTC10-02 KTL6-M5 KTL10-02
KLC6-01 KLC10-03 KLL6-01 KLL10-03 KTC6-01 KTC10-03 KTL6-01 KTL10-03
KLC6-02 KLC10-04 KLL6-02 KLL10-04 KTC6-02 KTC10-04 KTL6-02 KTL10-04
KLC6-03 KLC12-02 KLL6-03 KLL12-02 KTC6-03 KTC12-02 KTL6-03 KTL12-02
KLC6-04 KLC12-03 KLL6-04 KLL12-03 KTC6-04 KTC12-03 KTL6-04 KTL12-03
KLC8-01 KLC12-04 KLL8-01 KLL12-04 KTC8-01 KTC12-04 KTL8-01 KTL12-04
KLC8-02 KLL8-02 KTC8-02 KTL8-02

KLB-快拧螺纹三通 KLD-快拧螺纹三通 KTB-卡套螺纹三通 KTD-快拧螺纹三通
型号 Type 型号 Type 型号 Type 型号 Type
KLB4-M5 KLB8-03 KLD4-M5 KLD8-03 KTB4-M5 KTB8-03 KTD4-M5 KTD8-03
KLB4-01 KLB8-04 KLD4-01 KLD8-04 KTB4-01 KTB8-04 KTD4-01 KTD8-04
KLB4-02 KLB10-01 KLD4-02 KLD10-01 KTB4-02 KTB10-01 KTD4-02 KTD10-01
KLB6-M5 KLB10-02 KLD6-M5 KLD10-02 KTB6-M5 KTB10-02 KTD6-M5 KTD10-02
KLB6-01 KLB10-03 KLD6-01 KLD10-03 KTB6-01 KTB10-03 KTD6-01 KTD10-03
KLB6-02 KLB10-04 KLD6-02 KLD10-04 KTB6-02 KTB10-04 KTD6-02 KTD10-04
KLB6-03 KLB12-02 KLD6-03 KLD12-02 KTB6-03 KTB12-02 KTD6-03 KTD12-02
KLB6-04 KLB12-03 KLD6-04 KLD12-03 KTB6-04 KTB12-03 KTD6-04 KTD12-03
KLB8-01 KLB12-04 KLD8-01 KLD12-04 KTB8-01 KTB12-04 KTD8-01 KTD12-04
KLB8-02 KLD8-02 KTB8-02 KTD8-02

KLV-快拧弯头二通 KLE-快拧三通 KTV-快拧弯头二通 KTE-卡套三通
型号 Type 型号 Type 型号 Type 型号 Type
KLV-4 KLE-4 KTV-4 KTE-4
KLV-6 KLE-6 KTV-6 KTE-6
KLV-8 KLE-8 KTV-8 KTE-8
KLV-10 KLE-10 KTV-10 KTE-10
KLV-12 KLE-12 KTV-12 KTE-12
