选型安装表示方法 支架
Selection and Installation of Cable Tray Supports

架 支
支 吊 架
电缆桥架型号表示方法

Notation for types of Cable Trays XQJ-ZDJ

支架是支撑电缆桥架和电缆的主要部件，它由立柱、立柱底座、托臂等组
XQJ 形式 类 别 规 格
成。我厂生产的支架是根据日本、西德的同类产品设计而成；它具有结构简单、
Type Classification Specification
重量轻、成本低、强度大、造型美观等优点，可满足不同环境条件（工艺管道架

上、楼板上、墙壁上、电缆沟内）安装成不同形式（悬吊式、直立式、侧壁式、
表示规格或规格序号 单边、双边和多层等）的需要。
(用阿拉伯数字表示) 电缆桥架如需多层重载荷吊装时，要尽量采取双边敷设、避免偏载过大。
it denotes specification or the SN
(using Arabian number) 用户如需其它品种规格的支架、欢迎来图、来函或面洽订货。

表示类别种类序号
(用阿拉伯数字加英语字母表示)
it denotes sorting numbers (using
Arabian numerals and English
alphabet
Support
表示结构形式
(用中文第一个汉语拼音的大写字 XQJ-ZDJ
母)T为梯级式、P为托盘式、C为槽
式 The support, which is made of stand, stand base and bracket arm, is the main part to support the
it denotes structural type (T refers to
ladder type, P tray type, C refers to cables. The support produced in our factory is designed to the same kind of product in both Japan and
channel type) Germany. It has such advantages as simple structure, Light weight, Low cost, big strength and wonderful
model. It can meet different environmental conditions (such as, on the technological piping frame, on the
XQJ-DJ大跨距桥架系列
XQJ-DJ long span cable tray floors, on the walls and cable ditches) to be installed in different forms (such as, hanging style, standing
XQJ普通汇线桥架系列 style, side style, single, double and multilateral styles).
XQJ common cable tray
XQJ－Z整体拉制桥架系列 When hoisted with multilateral heavy Load, the cables should be Laid bilaterally to avoid being over
XQJ－Z integrated pulling cable tray Loaded.
XQJ-X高强轻型桥架系列
XQJ-X hih strength light cable tray If you need other support, you can order by sending your pictures, writing to us and coming to have
XQJ-ZH组合式桥架系列 a face-to-face talk with us.
XQJ-ZH commbined cable tray
XQJ-GSJ钢竖井系列
XQJ-GSJsteel shaft
LQJ铝合金桥架系列
LQJ al-alloy cable tray
FQH耐火桥架系列
FQH fire-proof cable tray
