4V300• Series 4V300• Series

We make the difference ISO9001:2008
Solenoid• Valve,• Air• Piloted• Valve Solenoid• Valve,• Air• Piloted• Valve

Overall• Dimension
Valve Valve
DJF 4V310-08 DJF
4V310-08
4V310-10
JELMP 4V310-10 JELMP
JELP/G JELP/G
MCS MCS
4V100 4V100
4V200 4V200
4A310-10 4V320-10
4V300
4V300 4V300
4V300
4V400 4V400
Manifold Manifold
SV SV
4V310-10B
3V1 3V1
JEL JEL
3VJZF 4V330-10 3VJZF
4VJZF 4V310-10 4VJZF
MVSD MVSD
VF,• VZ VF,• VZ
BM BM
4V320-08
4V320-10
Diaphragm Ordering• Code 4V320-08 4V320-10 Diaphragm
Coil Coil
2V 4V - 3 - 10 - 10 - B - AC220V - W - F 2V
2W 2W
2W(Big) 2W(Big)
2P Specification Series• Code Coil and Type Port• size Connection and Initial status Standard• • Voltage Wiring Joint 2P
2L 4V: 5/2 (3) way solenoid valve 300• Series 10: Single coil 08: 1/4″ Blank:• Threaded DC12V• • • • • DC24V Blank:• • Without• light• terminal 1• F-20• F•••• 2L
VX 4A: 5/2 (3) way air pilot valve 20: Double coil 10: 3/8″ B: Sub-plated mounted AC24V• • • • • 50Hz/60Hz LD: Brown with light terminal VX
PU 3V: 3/2 way solenoid valve 30C: Mid-position closed (for 5/2,5/3 way only) AC110V• • • 50Hz/60Hz LD1: White with light terminal PU
PU225 3A: 3/2 way air pilot valve 30E:• Mid-position exhausted NC: 3/2 way normal close AC220V• • • 50Hz/60Hz W: Lead wire PU225
2Q 30P:• Mid-position• pressed NO: 3/2 way normal open AC380V• • • 50Hz/60Hz 2Q
JEL5404 JEL5404
JEL6213 JEL6213
BU BU
Pulse Specification Pulse
JEL.JZF JEL.JZF
4H 4V310-08 4V320-08 4V330C-08 4V330E-08 4V330P-08 4V310-10 4V320-10 4V330C-10 4V330E-10 4V330P-10 4H
TSV Model 4A310-08 4A320-08 4A330C-08 4A330E-08 4A330P-08 4A310-10 4A320-10 4A330C-10 4A330E-10 4A330P-10 TSV
MPV MPV
Valve Type 5/2 way 5/3 way 5/2 way 5/3 way
4HV 4HV
2•
2•
2•
2•
HV,• K Effective Cross Section Area 25• mm (CV = 1.40) 18• mm (CV = 1.00) 30• mm (CV = 1.68) 18• mm (CV = 1.00) 4V330-08 4V330-10 HV,• K
4R Model 3V310-08 3V320-08 3A310-08 3A320-08 3V310-10 3V320-10 3A310-10 3A320-10 4R
FV FV
Valve Type 3/2 way
MSV MSV
2•
2•
Effective Cross Section Area 25• mm (CV = 1.40) 30• mm (CV = 1.68)
JM JM
•
ASC,• RE Port• Size Inlet,• Outlet, Exhaust Port ＝ G 1/4″ Inlet,• • Outlet＝ G 3/8″• • • Exhaust Port ＝ G 1/4″ ASC,• RE
QE,• QEA Working• Medium 40 Micron Filtered Air QE,• QEA
ST Operation Internal• piloted ST
HSV HSV
Working-pressure 0.15～0.8 MPa
Max. Test Pressure 1.2• MPa
Ambient Temperature 5～50 ℃
Operating Voltage Tolerance
Power Consumption AC:• 5.5• VA• • • • • DC:• 4.8• W
Connector Protection F• Class,• IP• 65
Wiring/Connector Cable / Lead Wire or DIN Connector
Switching Frequency 5 Cycles / Sec.
Response• Time 0.05 Sec.

2-|P 15 2-|P 16
