CT 电流互感器
CT current transformer

主要特点
Main Feature
● 块状结构，符合用户习惯

● 增加伞群结构，延长爬电距离
● 背部接线检修，满足小空间要求
● 窄长条结构，保证输出容量，测量精度

● 与电缆封罩配合，提高安全性能

● Block structure, in line with user habits
● Increase the structure of the umbrella group and extend the creepage distance
● Back wiring maintenance to meet small space requirements

● Narrow strip structure to ensure output capacity and measurement accuracy
● Cooperate with cable cover to improve safety performance

主要技术参数

The main technical parameters

电流比 Current ratio 等级 grade 最大容量 Maximum capacity
0.2S 15VA
5/5A-1250/5A
10P10 20VA
0.2S 15VA
5/5A-1250/5A
10P15 15VA
0.2S 15VA
5/5A-1250/5A 10P20 10VA
0.2S 15VA
0.5 15VA
5/5A-500/5A 10P10 15VA
0.2S 15VA
0.5 15VA
5/5A-500/5A 10P15 10VA
0.2S 10VA
0.5 10VA
5/5A-500/5A 10P20 10VA
0.2S 10VA
10P10 10VA
5/5A-500/5A 10P10 10VA
0.2S 15VA
0.5 15VA
600/5A-1250/5A 10P10 20VA
0.2S 15VA
0.5 15VA
600/5A-1250/5A 10P15 15VA
0.2S 15VA
0.5 15VA
600/5A-1250/5A 10P20 10VA
0.2S 15VA
10P10 15VA
600/5A-1250/5A
10P10 15VA
