RING TERMINAL RING TERMINAL

> >

(Wire Range) (Material) (Size)(mm) (Material Q`ty/reel Note (Wire Range) (Material) (Size)(mm) (Material Q`ty/reel Note
B D (Part No.) mm 2 AWG# D W E L Thickness) (Part No.) mm 2 AWG# D W E L Thickness) B

E L TO43851J-2 0.75-2.27 18-14 4.3 8.5 7.5 19.25 0.4 7000PCS TO13162G-2 0.5-1.5 20-16 13.0 16.0 22 28 0.5 3000PCS
TO43852J-2 0.75-2.27 18-14 Brass 4.3 8.5 7.5 19.25 0.5 7000PCS TO44702G-2 0.5-1.5 20-16 4.4 7.0 16.0 8.5 0.45 7500PCS
W
D
TO43853J-2 0.75-2.27 18-14 4.3 8.5 7.5 19.25 0.6 7000PCS TO44862J-2 0.3-0.75 22-18 4.4 8.6 22 21 0.6 7000PCS
E L TO50802G-0 0.5-1.5 20-16 Brass 5.2 8.0 22 17.4 0.5 7000PCS
TO51752K-2 0.75-2.5 18-14 5.1 7.5 16.7 6.7 0.5 8000PCS
W
TO57872G-0 0.5-1.5 20-16 5.7 8.7 22 19.9 0.8 7500PCS
(Wire Range) (Size)(mm) (Material TO84152K-3 0.75-2.5 18-14 8.4 15 6.2 22.0 0.6 2500PCS
(Part No.) Thickness)
D (Material) Q`ty/reel Note
mm 2 AWG# D W E L TO84162K-3 0.75-2.5 18-14 8.4 16.0 30.0 10.5 0.6 1500PCS
E L Line of join terminal
TO43901G-3 0.5-1.25 20-16 4.3 9.0 7.5 20.2 0.6 2500PCS
Brass
W
TO43902G-3 0.75-2.0 18-14 4.3 9.0 7.5 20.2 1.0 2500PCS
Line of join terminal
>
D (Wire Range) (Material) (Size)(mm) (Material Q`ty/reel
(Wire Range) (Size)(mm) (Part No.) Thickness) Note
D (Material Q`ty/reel mm 2 AWG# D W E L
(Part No.) (Material) Thickness) Note
mm 2 AWG# D W E L
E L TOJ15453G-1 0.5-1.25 20-16 1.5 4.5 3.8 12.5 0.5 10000PCS
TO51752A-2 1.25-2.27 16-14 Brass 5.1 7.5 5.9 16.3 0.5 8000PCS TOJ27485G-0 0.3-0.75 22-18 2.7 4.8 3.8 13.0 0.3 33000PCS
W L W E D
W/O Hole
TOJ44702G-0 0.5-1.5 20-16 4.4 7.0 3.8 15.9 0.45 8000PCS Inside
TOJ53855G-0 0.75-2.5 18-14 4.4 8.5 3.8 19.1 0.5 7000PCS

(Wire Range) (Size)(mm)
D (Material) (Material Q`ty/reel Note
(Part No.) Thickness)
mm 2 AWG# D W E L
E L
W TO53852K-2 0.75-2.27 18-14 Brass 5.3 8.5 7.5 19.25 0.5 7000PCS

D (Size)(mm)
(Wire Range) (Material Q`ty/reel
(Part No.) (Material) Thickness) Note
mm 2 AWG# D W E L
E L
TO54103K-2 2.27-5.3 14-10 Brass 5.4 10.0 8.0 24.0 0.8 2500PCS
W

(Wire Range) (Size)(mm)
D (Material) (Material Q`ty/reel
(Part No.) Thickness) Note
mm 2 AWG# D W E L
E L
TO54123K-2 2.0-3.3 14-12 5.4 12.0 8.0 25.0 0.8 4000PCS
Brass
W
TO63952G-2 0.75-2.27 18-14 6.3 9.5 8.2 20.1 0.5 6000PCS
