Page 28 - 重庆智电科技有限公司
P. 28
High-voltage complete
switchgear series
高压成套开关设备系列
箱型固定式金属封闭开关设备
Box type fixed
metal enclosed switchgear
XGN2-12
电 科 技 重 庆 智 限 公 有 司
概述 / Overview
XGN2-12 箱型固定式金属封闭开关设 ( 简称“开关设备”)，适用于额定电压为 3.6~12kV、50Hz，额定电流 630A~3150A 三相交流单母线、双母线、
单母线带旁路系统，作为接受和分配电能之用。可满足各种类型发电厂、变电站 ( 所 ) 及工矿企业使用要求。
本产品符合国家标准 GB3906《3~35kV 交流金属封闭开关设备》、IEC60298《交流金属封闭开关设备和控制设备》、及 DL/T402、DL/T404 标准，达到“五
防”闭锁要求。
XGN2-12 box type fixed metal enclosed switch set (referred to as "switching device"), suitable for rated voltage 3.6~12kV, 50Hz, rated current
630A~3150A three-phase AC single bus, double busbar, single busbar bypass system , as a means of receiving and distributing electrical
energy. It can meet the requirements of various types of power plants, substations (houses) and industrial and mining enterprises.
This product complies with the national standard GB3906 "3 ~ 35kV AC metal-enclosed switchgear", IEC60298 "AC metal-enclosed
switchgear and control equipment", and DL/T402, DL/T404 standards, to achieve the "five-proof" blocking requirements.
...................................................................................................
