GC• Series GC• Series

Air• Source• Treatment We make the difference ISO9001:2008 Air• Source• Treatment
(3• or• 2• Combination)• (3• or• 2• Combination)•

Overall• Dimension
FRL FRL
JC JC
FE FE
GC
GC GC
GC
ZYR10 GC• 200 ZYR10
MAR300LK MAR300LK
AC, BC AC, BC
AFC,• BFC AFC,• BFC
AF,• BF AF,• BF
AR,• BR AR,• BR
AFR,• BFR AFR,• BFR
AL,• BL AL,• BL
JAC JAC
JAF JAF
JAR JAR
GС GFС
GС
GFС
JAW JAW
JAL JAL
PTH PTH
JAD JAD
Ordering• Code Symbol

GC - 200 - 08 - M - F - 1 - W - G
型 号
Code Series Port• Size Drain Pressure• Gauge Scale Filter• Accuracy Thread GC• 300
GC:• 3• Combination 200• Series 06：PT 1/8 Blank:• Semi-auto• drain F: Square type 1:• MPa Blank: 40 μ Blank:• PT
GFC:• 2• Combination 300• Series 08：PT 1/4 M:• Manual• drain C:• Traditional• type 2:• Psi W: 5 μ G:• PS GC• 400
GFR 400• Series 10：PT 3/8 A:• Auto• drain T:• NPT
15：PT 1/2
GF:• Filter
GR:• Regulator
GL:• Lubricator

*Note:• No• Auto• Drain• type• is• available• on• GC• 200• Series.
**Note:• Max.• adjustable• pressure• is• at• 0.4• MPa• on• Low• pressure• type.•

Specification

Model GC200-06 GC200-08 GC300-08 GC300-10 GC300-15 GC400-10 GC400-15
Working• medium Air
Port• Size PT• 1/8 PT• 1/4 PT• 1/4 PT• 3/8 PT• 1/2 PT• 3/8 PT• 1/2
Filtration 40 μ or 5 μ
Adjustable• pressure• range 0.15• ~• 0.9• MPa Dimension•
Maximum• working• pressure 1.0• MPa
Proof• Pressure 1.5• MPa Model• /• Symbol A B C D E F G H I J K
Operating• Temperature• Range 5 ~ 60 ℃ GC300-08 71 41.5 35 PT• 1/4 PS• 1/8 188 143 6.5 64 9 188
Capacity• of• Filter• Cup 10• CC 40• CC 80• CC GC300-10 71 41.5 35 PT• 3/8 PS• 1/8 188 143 6.5 64 9 188
Capacity• of• Oil• Cup 25• CC 75• CC 160• CC GC300-15 71 41.5 35 PT• 1/2 PS• 1/8 188 143 6.5 64 9 188
Recommended• Lubrication ISO• VG• 32• or• Same• Grade GC400-10 85.5 50 40 PT• 3/8 PS• 1/4 248 166.5 8.6 84 12 216
Weight 580• g 1300• g 2358• g GC400-15 85.5 50 40 PT• 1/2 PS• 1/4 248 166.8 8.6 84 12 216
Filter GF• 200-06 GF• 200-08 GF• 300-08 GF• 300-10 GF• 300-15 GF• 400-10 GF• 400-15
Components Regulator GR• 200-06 GR• 200-08 GR• 300-08 GR• 300-10 GR• 300-15 GR• 400-10 GR• 400-15
Lubricator GL• 200-06 GL• 200-08 GL• 300-08 GL• 300-10 GL• 300-15 GL• 400-10 GL• 400-15

3-|P 07 3-|P 08
